Used Cisco 2960 Series 48 Port Gigabit Ethernet POE 740W Switch WS-C2960S-48FPS-L
The WS-C2960S-48FPS-L is different from the WS-C2960S-48LPS-L in the PoE capabilities, because Cisco WS-C2960S-48FPS with Full PoE function can offer 740W PoE Power total with 24 ports up to 30W per switch ports or 48 ports up to 15.4W per switch port. But Cisco Catalyst Switch 2960S-48FPS-L and 2960S-48LPS-L share a similar datasheet with 4 One Gigabit Ethernet SFP uplink ports and optional Cisco FlexStack stacking supporting 20 Gbps of throughput. Both are Catalyst 2960-S models with LAN Base Software.
Product Code | WS-C2960S-48FPS-L |
Enclosure Type | Rack-mountable - 1U |
Feature Set | LAN Base |
PoE capacity | 740W |
Uplink Interfaces | Four 1G Small Form-Factor Pluggable(SFP) |
Interfaces | Gigabit Ethernet |
Downlink Ports | 48 × Ethernet 10/100/1000 PoE+ ports |
Power Over Ethernet (PoE) | PoE |
Expansion Slot(s) | 1 (total) / 1 (free) x Stacking Module |
Switching capacity | 88Gbps |
Forwarding/Filtering Rate: | 77.4 Mpps |
DRAM | 128 MB |
Flash Memory | 64 MB |
Dimensions | 44.5 × 38.6 × 4.5 cm |
Package Weight | 10.65 Kg |
WS-C2960S-48FPS-L
