Fortinet FortiGate-90E Enterprise Network Security Firewall FG-90E,16x GE-RJ45 Ports
The FortiGate 90E offers an excellent network security solution in a compact desktop form factor for enterprise branch offices and mid-sized businesses. Protect against cyber threats with industry-leading secure SD-WAN in a simple, affordable and easy to deploy solution
Interfaces | |
1. USB Management Port | 4. 2x GE RJ45 DMZ/HA Ports |
2. Console Port | 5. 12x GE RJ45 Ports |
3. 2x GE RJ45 WAN Ports |
GE RJ45 Ports | 16 |
USB Ports | 1 |
Console (RJ45) | 1 |
Firewall Throughput | 4 Gbps |
Latency | 182 μs |
Throughput | 375 Kpps |
Concurrent Sessions | 1.2 Million |
New Sessions/Second | 27,500 |
Policies | 5,000 |
IPsec VPN Throughput (512 byte) | 245 Mbps |
Gateway-to-Gateway IPsec VPN Tunnels | 200 |
Client-to-Gateway IPsec VPN Tunnels | 2,500 |
SSL-VPN Throughput | 95 Mbps |
Concurrent SSL-VPN Users | 200 |
SSL Inspection Throughput 3 | 300 Mbps |
Application Control Throughput 2 | 510 Mbps |
CAPWAP Throughput | 950 Mbps |
Virtual Domains | 10 / 10 |
Switches Supported | 8 |
FortiAPs | 32 / 16 |
FortiTokens | 100 |
Registered FortiClients | 200 |
IPS Throughput 2 | 1 Gbps |
IPS Throughput 2 | 470 Mbps |
NGFW Throughput 2, 4 | 375 Mbps |
Power Consumption | 22.8 W / 27.36 W |
Current (Maximum) | 100V AC / 1.5A |
