Specifications
Brand Name :
BRAUSSE
Model Number :
1050
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
50000＄-80000＄
Payment Terms :
L/C, T/T
Supply Ability :
2 set
Delivery Time :
45DAYS
Packaging Details :
standard packaging
Stock Range :
Cardboard: 80-600 g/m²
Corrugated board :
thickness ≤ 4mm
Max. Sheet Size :
1050 × 750 mm
Min. Sheet Size :
400 × 360 mm
Max. Mechanical speed :
7500 s/h
Max. Cutting Pressure :
300 T
Description

Modle: BRAUSSE 1050 Automatic Die Cutting Machine

BRAUSSE 1050 Automatic Die Cutting & Stripping Machine.Stock Range : Cardboard: 80-600 g/m

Stock Range Cardboard: 80-600 g/m² ; Corrugated board: thickness ≤ 4mm
Max. Sheet Size 1050 × 750 mm
Min. Sheet Size 400 × 360 mm
Max. Mechanical speed 7500 s/h
Max. Cutting Pressure 300 T
Max. Cutting Size 1040 × 720 mm
Inner Chase Size 1080 × 745 mm
Cutting Plate Size 1080 × 736 mm
Min. Gripper Margin 8 mm
Max. Pile Height at Feeder 1250 mm
Max. Pile Height at Delivery 1150 mm
Max. Air Compressor Displacement 0.36 m³/min
Dimensions(L × W × H) 6065 × 4280 × 2030 mm
Gross Weight Approx. 14.5 T
Total power requirement 19 kw

Stable & High speed

- Preloading device; Non-stop feeder and delivery

- Double sheet detector ; Accurate Side lay & Front lay

- Precision worm gear crank toggle driving system

- Triple movement of stripping frames

- Complete lost-sheets control throughout the entire machine

Durable

- Double cam driven gripper opener and front lay swing frame

- High quality gripper bar and pre-stretched gripper chain (IWIS)

- Key components’ suppliers certified by the Group

- Easy maintenance

Safety

- Gripper bar safety lock device

- Torque limit safety clutch

- Photo sensor safety barrier at pallet table

- CE standard safety system for safe Operation

- Emergency stop at arm length
