3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping
Specifications
Brand Name :
LSXC
Model Number :
LSX
Certification :
CCC ISO DOT
Place of Origin :
China
MOQ :
1 Unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 unit per month
Delivery Time :
30 working days
Packaging Details :
Without packaging or according to customer requirements
Axles :
3 axles
Tire :
12 pcs
Material :
Steel
King pin :
JOST brand 2.0 or 3.5 inch (bolted or welded)
Platform :
3mm-thick checkered plate
Condition :
New/used
Function :
Transport 20ft 40ft container and Heavy Duty Equipment
Color :
By customer
Light :
LED light (specially intended for oversea market)
Use :
Truck Trailer
Description
3 Axles 60 Tons 20FT 40 FT Container Shipping Flatbed Truck Semi Trailer Truck
Flatbed Truck Trailer Of Product Characteristics:
> Variety of Sizes - 20ft, 40ft, 45ft, 48ft, 53ft, etc, both skeleton type and flatbed type.
> Light Weight - Light tare weight with strong loading capacity.
> Perfect Welding - professional welding of main beam guarantee stability and durability.
> Modern Transportation Accessories - spare tire carriers, water tank, fuel tank, etc.

Flatbed Truck Trailer Of Product Parameters:
Tare Weight About 7.1T
Dimension(mm) 12500x2500x1550mm
Loading capacity(ton) ≤60T
Axles 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand
Tire 12 units, 12.00R22.5 or 315/80R22.5
Rim 9.00-22.5 or 9.75-22.5
Suspension Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand)
Spring Leaf 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12
(specially intended for overseas markets)
King Pin JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Side Beam 16mm or 18mm steel channel (material: Q235 steel)
Platform 3mm-thick checkered plate
Brake Chamber WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Twist Locks 4,8,12 sets (lifting or screw type) (specially intended for oversea market)
valve WABCO valve (specially intended for oversea market)
ABS Optional
Light LED light (specially intended for oversea market)
Voltage 24V
Socket(Receptacle) 7-pin Socket (for 7 wire harness)
Tool Box 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats

Flatbed Truck Trailer Of Details:

3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping


Workshop of Dump Semi Truck Trailer:

3mm 3 Axles Flatbed Truck Trailer 60 Tons 20FT 40 FT Container Shipping

Flatbed Truck Trailer Of Advantages:

1. Extensive usage Fast and efficient. Mainly used for the middle&long-distance transport of the medium&heavy-duty and bulk goods, widely used for variety of the cargoes.

2. The whole vehicle adopts the advanced computer-aided design software to optimize the design,make the Frame reasonable offload&scientific design by FEA( Finite Element Analysis) according to requirement of the vehicle carrying quality.

3. Axles, tires and other supporting parts are all well-known products purchased from domestic and foreign manufacturers.

4. The product quality and reliable, widely used, has become the vehicle of choice for long-distance freight vehicles. The quality of this product is reliable,extensive usage, has become the preferred models of middle&long-distance freight vehicles.


Our service:

1.We will provide you one-to-one service throughout the entire process, answering questions about products before sales and checking and debugging equipment after sales, and assisting in equipment maintenance and testing.

2.Our company promises to provide one-year warranty for all new equipment and free consulting service for life.

3.After the equipment fails, we will reply to you within 24 hours and give you a solution within 48 hours.

FAQ:

Q: I want to transport the truck by container, is it ok?

A: Yes, it is ok, but we need take apart the truck and you should reinstall in your country.

Q: How about your product quality?

A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.

Q: I want to be your agent in my country, is that ok?

A: It’s ok, if your quantity is big, we will consider. For the first time 50 units is ok.

Q: How about your company's service, especially after-sale service?

A: we can satisfy your demand within 3-7 days. We always do our best to solve all the problems and put our customer's interests in the first place.

Q: What is your payment terms?

A: You can choose to the 30% prepaid and 70% paid before delivery or you can choose the LC 100% at sight.

Q: What is your lead time?

A: Usually it is 30-50 days after deposit received.
