Specifications
Brand Name :
ALSTON
Model Number :
ATM3316BCT
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$14000/unit-$19000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30units per month
Delivery Time :
15-30 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Bulk Cement Trailer
Type :
Truck Trailer
Suspension :
Mechanical Suspension
Axle :
13 Ton Fuwa Brand
Landing Gear :
JOST Brand Two-speed
Loading Weight :
60Ton
Description

Bulk Cement Trailer Aluminum Alloy Bulk Cement Tanker Semi Trailer

Bulk Cement Trailer Features:

1. we adopt Q235 for the tanker body and Q345 for tanker ending.

2. The tanker size is customized. Brand of parts are optional.

3. The air bag type has a large carrying capacity, and the discharge speed is fast and the residual amount

is small. The integrated tanker has the characteristics of high overall strength, good rigidity, good pressure

bearing and good performance.

4. The bulk cement tanker :it uses the latesr fluidized structure with the characteristics of large capacity, low

center of gravity, few remnants, simplified structure, quick discharging, which is easy to operate and maintain.

5. Steel struture : steel frames are built with top-class hot rolled or cold rolled steel plate. automatic welded

longitudinal beam, advanced sanding and painting process are preliminary treatment.

6. The tanker body of bulk cement trailer adopts a double-cone internal tilting structure, double-pipe intake and

double-barrel feeding, and its discharge speed and residual rate meet the industry standard requirements.

BULK CEMENT TRAILER SPECIFICATIONS

Trailer Model 40 M3 BULK CEMENT SEMI TRAILER

Overall Dimension

(Lx W x H)(mm)

 10700x2500x3950mm
Function transport bulk powder
Loading Weight( KG) 54000
Thickness(mm)

Tank body: Q235 5mm carbon steel

End plate: Q235 5mm carbon steel
Air compressor 12m3/minute Bohai brand
Engine Diesel engine: Weichai Tianhe 4102
Compartment 1 inner fluidized bed: air bag
Axle 3x13Ton, ZY brand
Suspension system Mechanical leaf spring suspension
Leaf spring 90(W)mm*13(Thick)mm*10 Layer
Manhole cover 500mm manhole cover. 2 sets
Discharge valve 4〞butterfly valve
Discharge pipe 4〞
Landing Gear 28Ton, double speed,Yahua brand
Tire 12R22.5, Taitong brand 12units
Traction Pin 2” or 3.5” bolts in, changable
Spare Wheel Bracket 2 pieces
Tool Box 1 Standard
Side guard According to customer’s requirement
Brake system Dual Line braking system
Emergency valve Standard or WABCO
Brake air chamber Six big double air chambers
Electrical system 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.
Painting Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um,A layer of anti-rust paint,two-layer finish.
Packing Polish with wax before shipping

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Ro-Ro Ship

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Bulk Ship

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Container

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Flat Rack

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer

Aluminum Alloy Bulk Cement Trailer , 60 Ton Bulk Cement Tank Trailer
