Specifications
Brand Name :
ALSTON
Model Number :
ATM3316LBT
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$12000/unit-$18000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30 units per month
Delivery Time :
15-30 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Lowbed Semi Trailer
Type :
Truck Trailer
Suspension :
Mechanical Suspension
Axle :
13ton Fuwa brand
Landing Gear :
JOST brand Two Speed
Loading Weight :
100 Tons
Description

Hydraulic 2/3/4 Axle Heavy Duty Bulldozer Transport Lowboy Semi Trailer

Lowbed Semi Trailer Features:

Lowbed semi trailers can be put to fair use if you face any tall cargo movement restriction. These trailers
accommodate the high load and transfer it without compromising the legal procedures or the shipment’s safety.
A customizable semi-low bed trailer allows the user to lower the rear part for extra ease in transporting the loaded
freight. Lowbed semi trailers have a bed height of almost 4 feet. It is generally used to carry the freight of relatively
greater size than the bed height. Hence, it is used in various industries, including heavy-cargo transportation and
trucking, among others. Lowbed semi trailers have multiple capacities, and for each capacity type, it uses a different
number of axles from 2, 3, 4 axles to 7, 8 axles.

The structure of lowbed semi trailers secures the loaded cargo. You can transport freight without worrying
about undue damage. This trailer’s frame is made from high-strength material, which gives the required
strength to endure high pressure. Removable or folding goose-neck lowbed semi trailer allows loading
heavy cargo from the front instead of rear or side parts. This provides an added level of safety, especially
when moving heavy equipment. Hence, you can use these trailers in your business to safely transfer the cargoes.


LOWBED SEMI TRAILER SPECIFICATIONS

Dimension and Weight
Overall Dimension(mm)13000x3000x1650mm
Working Deck Dimension(mm)9000x3000x1350mm
Platform thickness(mm)4mm Diamond Plate
Main Beam“H”main beam design,Q345B carbon steel,
the height of the beam is 500 mm,
upper plate is 16mm,down plate is 18mm, middle plate is 10 mm.
Wheelbase7,650mm+1,310mm+1,310mm+1,310mm
Payload60,000kg
Tare weight9,000kg
G.V.W.R.69,000kg
FunctionTo transport bulk goods or heavy equipment like loader or excavator
Running System
Axle13Ton, ZY brand optional FUWA brand,
one hundred fifty thousand Kilometers no need maintenance
Axle NumberFour
Tire11.00R20, 16 pcs Taitong brand
Rim8.0*22.5 steel disc wheel, 10 holes ISO, 16 pcs
Suspension systemCommon Mechanical Suspension
Steel Spring10/10/10 leaf spring with 90mm(W) *13mm(thickness)
Electrical SystemChinese standard 24V lighting system
Brake system:Dual line pneumatic brake, SAE hose and connector,optional ABS
Brake air chamber8 units T30/30 spring brake chambers
Emergency relay valveWabco relay valve
Traction/King Pin2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster
Landing GearZhenhua brand 28ton external two speed telescopic manual operation. 2,500mm behind the kingpin location

2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport

Container

2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport

Ro-Ro Ship

2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport

Bulk Ship

2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport
2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport
2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport

PRODUCTION

2 3 4 Axle Hydraulic Low Bed Trailer For Bulldozer Transport
