Specifications
Brand Name :
ALSTON
Model Number :
ATM3316FBT
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$7500/unit-$10000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30 units per month
Delivery Time :
15-30 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Used Flatbed Semi Trailer
Suspension :
Mechanical Suspension
Landing Gear :
JOST brand Two Speed
Brake System :
WABCO Valve
Tyre :
12R22.5
Size :
12500*2500*1600mm
Description

Flatbed Trailer Transport 40ft Container 3 Axle Used Flatbed Semi Trailer

Used Flatbed Semi Trailer Features:

Our used 3 axle flatbed trailer is a basic type of the semi-trailer, versatile in medium and long-distance transportation.

It is suitable for transporting containers, namely 40ft flatbed semi trailer can transport one 40ft container or

two 20ft containers. Used flat decks also can be used to transport building materials, lumber and other cargoes.
About the main configuration: We adopt Q345 or T700 steel to make the frame to improve the trailer’s strength.

The configuration will be designed by our engineers according to clients’ requirements.

* Finite element analysis used in vehicle to promote product performance.

* Whole trailer body electrophoresis Painting, resistance, painting effect can be kept above 10 years.

* High Stength full thickness Steel,titanium content of 0.98‰, which ensure beam and frame’s toughness and strength.

* 42 tough ribs design, which ensure the safety and carrying capacity of trailer.

* Specially designed anti-Tire abrasion suspension system, prevent tire offset after loading.

USED FLATBED SEMI TRAILER SPECIFICATIONS

Trailer Model 3 Axle flatbed Container Semi Trailer
Function Carry 40ft or 2*20ft container or other stuff

Overall Dimension
(Lx W x H)(mm)

 12500mm*2500mm*1600mm
Tare Weight(KG) 6350kg
Loading Weight( KG) 40000kg
Total Weight(KG) 46350kg
Axle Brand 3*13TON Axle FUWA Brand
Wheelbase(mm) 7450+1310+1310
Suspension system Mechanical Leaf Spring Suspension
Leaf spring 90(W)mm*13(Thick)mm*10 Layer
The material of Main beam Q345B carbon steel,The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8 mm.
Side beam Q235 16# channel steel
Platform plate 3mm Diamond plate
Container Twist Locker 12pcs container lock
Tire Type and quantity 12R22.5 12units
Rim 9.00-22.5
Traction Pin 2” or 3.5”
Spare Wheel Bracket 2 pieces
Tool Box 1 Standard
Landing Gear 28ton single action supporting legs
Brake system Dual Line braking system
Brake air chamber Six double chamber
Electrical system 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.


3 Axle Used Flatbed Semi Trailer , 12.5m Used 40 FT Container Trailer
3 Axle Used Flatbed Semi Trailer , 12.5m Used 40 FT Container Trailer
3 Axle Used Flatbed Semi Trailer , 12.5m Used 40 FT Container Trailer
3 Axle Used Flatbed Semi Trailer , 12.5m Used 40 FT Container Trailer
