Specifications
Brand Name :
ALSTON
Model Number :
ATM3316FBT
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$7500/unit-$10000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30 units per month
Delivery Time :
15-30 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Used Flatbed Semi Trailer
Suspension :
Mechanical Suspension
Axle :
4 Axle
Size :
12500*2500*1600mm
Loading Weight :
80ton
Material :
Steel
Description

Used Truck Trailer 4 Axle 80ton 40 ft 45ft Semi Truck Flatbed Trailer

Used Flatbed Semi Trailer Highlights:

1. Flatbed semi trailer suitable for container transportation and other dry bulk, such as wood, bagged cement,

floor tiles, glass, steel, etc.;
2. Flatbed semi trailer uses high-strength international steel, light weight, guarantees deformation resistance

(no permanent deformation), and shock resistance;
3. Flatbed semi trailer frame adopts automatic submerged arc welding, beautiful weld seam and reliable performance;
4. Flatbed semi trailer has a simple structure, convenient disassembly and maintenance, and reduced maintenance costs;
5. Customized design to meet different customers’ needs.

USED FLATBED SEMI TRAILER SPECIFICATIONS

Trailer Model 4 Axle flatbed Container Semi Trailer
Function Carry 40ft or 2*20ft container or other stuff

Overall Dimension
(Lx W x H)(mm)

 12500mm*2500mm*1600mm
Tare Weight(KG) 6350kg
Loading Weight( KG) 40000kg
Total Weight(KG) 46350kg
Axle Brand 4*13TON Axle FUWA Brand
Wheelbase(mm) 7450+1310+1310
Suspension system Mechanical Leaf Spring Suspension
Leaf spring 90(W)mm*13(Thick)mm*10 Layer
The material of Main beam Q345B carbon steel,The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8 mm.
Side beam Q235 16# channel steel
Platform plate 3mm Diamond plate
Container Twist Locker 16pcs container lock
Tire Type and quantity 12R22.5 16units
Rim 9.00-22.5
Traction Pin 2” or 3.5”
Spare Wheel Bracket 2 pieces
Tool Box 1 Standard
Landing Gear 28ton single action supporting legs
Brake system Dual Line braking system
Brake air chamber Six double chamber
Electrical system 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.
