Specifications
Brand Name :
ALSTON
Model Number :
ATM3316FTT
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$14000/unit-18000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30 units per month
Delivery Time :
15-30 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Fuel Tanker Semi Trailer
Size :
11500x2500x3900mm
Loading Capacity :
35000 Liters
Axle :
3x13ton
Kingpin :
JOST 2"(50mm)or3.5"(90mm)
Tyre :
12R22.5
Description

Fuel Trailer Tanker 35000 Liters Fuel Tank Trailer Oil Tanker Trailer

Fuel Tanker Semi Trailer Description:

Our fuel tanker trailer choose Q345B carbon high-tensile steel material, welded by automatic Submerged-Arc

processes. According to clients' requirements, we can customize different volumes and compartments for

fuel tanker semi trailers.

Production Process
1. Steel auto cutting.
2. End plate bulging machine makes end plate more accurate.
3. Canning machine makes tanker body more beautiful and tight.
4. Tanker body auto welding.
5. Chassis welded by experienced workers.
6. Dust-free painting.

FUEL TANKER SEMI TRAILER PARAMETERS

Dimension and Weight
Overall Dimension(mm) 11500x2500x3900mm
Wheelbase 7,500mm+1,310mm+1,310mm
Payload 40,000kg
Tare weight 10,000kg
G.V.W.R. 50,000kg
Function transport Fuel, Oil, Diesel
Tank
Volume 42000L
Thickness(mm) Material Q235 carbon steel
Tank body and separate compartment plate: 5mm
Dish end plate: 6mm
Welding standard All welding are to be done by qualified welder per applicable national standard
Compartment 3 compartments ( 3*14000L )
Manhole cover 3 units Safety manhole with breath valve, Aluminum, diameter 500mm.
Discharge valve 3units 3” API valve with dust cover, aluminum Henghe Brand
Bottom valve 3 units 4 inch Pneumatic aluminum valve, 1pcs, Henghe Brand
Discharge pipe 3〞seamless steel tube, 6m
Tanker body test Hydrostatic test to 5 psi (35 Kpa) on each compartment
Running System
Axle 14Ton, L1 brand optional FUWA brand, 3Axles, one hundred fifty thousand Kilometers no need maintenance
Axle Number Three
Tire 12R22.5, 12 pcs. Taitong brand
Rim 9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs
Suspension system Mechanical Suspension
Steel Spring 10/10/10 leaf spring with 90mm(W) *13mm(thickness)
Electrical System Chinese standard 24V lighting system
Brake system: Dual line pneumatic brake, SAE hose and connector,no ABS
Brake air chamber 6 units T30/30 spring brake chambers
Emergency relay valve Wabco relay valve

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

Flat Rack Container

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

Container

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

Bulk Ship

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

Ro-Ro Ship

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

Our Workshop:

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer

35000 Liters Fuel Tanker Semi Trailer , 3x13T Tri Axle Tanker Trailer
