Drone Detection and Decoy Equipment, 5m Position Accuracy, 5km Detection Range, 800m Deceptive Navigation Range, Support GPS, Glonass, BDS, GAL Modes
Drone Detection and Decoy Equipment, 5m Position Accuracy, 5km Detection Range, 800m Deceptive Navigation Range, Support GPS, Glonass, BDS, GAL Modes
Specifications
Brand Name :
Tabebuia
Model Number :
Anti Drone-TB-II
Place of Origin :
China
Price :
$58,669.00
Detection frequency range :
900MHz、1.2GHz、1.4GHz、2.4GHz、5.2GHz、5.8GHz
Positioning accuracy :
5m(For some DJI models)
Detection Range :
5km
Simulated Navigation Mode :
GPS、Glonass、BDS、GAL
Navigation Spoofing Range :
800m
Protection Rating :
IP67
Power Consumption :
60W
Weight :
18kg
Size :
512*462*232mm
Description

Overview

5m Position Accuracy, 5km Detection Range, 800m Deceptive Navigation Range, Support GPS, Glonass, BDS, GAL Modes, Drone Detection and Decoy Integrated Equipment

By integrating DroneID decoding and navigation spoofing technology, the system can achieve specified trajectory spoofing for DJI series drones. For non-DJI drones, it can simulate no-fly zones to enforce landing or repel intruding UAVs.


Features

  • Real-time analysis of drone broadcast channels and precise location determination for drones and pilots;
  • Map interface clearly displays drone locations and integrates with network management software for centralized control;
  • White and black list functions filter out whitelisted drones, warning and countermeasuring only blacklisted ones;
  • Integrated four-mode navigation deception module covering mainstream drone frequencies;
  • Countermeasure include no-fly zone simulation, specified flight paths, and arbitrary angle displacement.


Specifications

Monitoring frequency range

900MHz,1.2GHz,1.4GHz,2.4GHz,5.2GHz,5.8GHz

Positioning accuracy

5m(For some DJI models)

Detection Range

5km

Simulated Navigation Mode

GPS,Glonass,BDS,GAL

Navigation Spoofing Range

800m

Protection Rating

IP67

Power Consumption

60W

Weight

18kg

Size

512*462*232mm
