6x4 Utility Dump Truck 20 - 25 Tons Loading 3 Axle MAN F2000 F3000 Cabin
6x4 Utility Dump Truck 20 - 25 Tons Loading 3 Axle MAN F2000 F3000 Cabin
6x4 Utility Dump Truck 20 - 25 Tons Loading 3 Axle MAN F2000 F3000 Cabin
6x4 Utility Dump Truck 20 - 25 Tons Loading 3 Axle MAN F2000 F3000 Cabin
Specifications
Brand Name :
SHACMAN
Model Number :
SX3255
Certification :
ISO9001
Place of Origin :
Shandong
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cabin :
MAN F2000
Body material :
Q235
Steering :
Power-assistant, LHD/ RHD
Color :
According your request
HS Code :
8704239000
Description

SHACMAN Utility 3 axle Dump Truck , 20 - 25 tons tipper truck , F2000 F3000 6x4 SHACMAN Dump truck

Specifications:

Cabin Air suspension MAN F2000 cab, double sleeper, hydraulic shock absorb adjustable seat
safety belt, adjustable steering, warm air system, sunroof, sun cap, bumper
Engine Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.
Model: WD615.46 European technology WEICHAI with MAN EVB technology
MAX Horse power: 340HP/243KW,380HP/279KW
Gear box Applied American technology Max torque:1500NM
Model: FAST RT-11509C, 12JS160T
Speed: 9/12speed, 1/2reverse
Axle(front/rear)
Front axle 6.5ton STR technology non-driving steering axle
Tandem 16ton MAN technology double reduction, hub redactor driving axle,
Clutch D430 diaphragm type, single dry frictional disc, hydraulic boosting.
Brake Service brake: Double circuit pneumatic brake
Parking brake: Spring-Power drum brake
Engine brake: Engine exhaust brake(EVB)
Steering ZF technology, driver sit at the left hand side
Tyre 12+1 spare tyre with rim
11.00-R20/ 12.00R20 tyre
Suspension system: strongthen heavy duty Leaf spring type
Front/Rear 13/13/12
Dump body:
Inside size of Body(mm): 5600x2300x1500, 8x6mm, made of high intensity steel
Lifting type: HYVA front lifter type hydraulic system.
Overall dimension(mm): 11874x2490x3450(Length x width x height)
Wheelbase 3800+1350mm
Track:
Front/Rear 2050/1800
Approach/Departure angle 18/14
Front /Rear overhang 1525/2699
Max speed 77km/h
Kerb weight: 13500kg
Oil tank capacity 300L fuel tank

How to choice the lifting type and lifting system

1. The general purpose self-unloading vehicle is recommended to select a tripod magnifying lifting mechanism, which has a history of 40 years in our country and is relatively mature in technology. It is suitable for a car with a length of 4~6 meters.

2. Reasonable arrangement, the force of each component will not exceed the bearing capacity of the parts, and the system oil pressure is small to ensure the service life of each sealing part;

3. Select high-quality hydraulic cylinder. The hydraulic cylinder is the power component of lifting the car, choosing the products with quality assurance.

4. A self-unloading car with a length of more than 6 meters is generally used in the top lift structure of the multi-stage cylinder;

5. The lifting structure of the double cylinder is generally used for a dump truck of 3 ~ 4 m.

Let's show you our Product Advantages


(1) Competitive Factory Price and Excellent Quality
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.
