8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional
Specifications
Brand Name :
FAW
Model Number :
CA3161
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cabin :
J5K, Dragon V
Capacity :
>8 tons
Color :
White, yellow
Brand :
FAW
HS Code :
8704239000
Steering :
LHD,RHD
Description

Two axles 8 - 10 Tons Utility Dump Truck , City multipurpose Dumper Tipper truck , Small Dump truck FAW

Several problems to pay attention to when installing the type:

1. The carriage of bulk items must be used with bucket carriages;

2. Special attention should be paid to the height and lifting stability of the carriages when the carriage length is greater than 5.6 meters;

3. It is not possible to transport the earth stone party with the coal transport. General coal vehicle height is 1.6 ~ 1.6 meters, the length of the how this type of vehicle design is a lightweight goods (specific gravity is less than 1.2), used to transport conditions may have problems with lifting poor stability, serious can cause lifting rollover accident;

4. Do not use the shovel carriage to transport the sticky goods such as silt and clay. The structure of the dipper compartment makes the sticky goods more difficult to unload;

5. When selecting a dump truck for iron ore powder, it is necessary to make a statement with the manufacturer to select a carrier for iron ore powder.

6. When used for paving asphalt transportation, the lifting mechanism requires slow lowering device.

Specifications:

Brand FAW J5K
Name Dumper/Tipper truck
Model CA3161/ CA3120
Overall dimension(LXWXH) 6350mmX2400mmX2680mm
Van dimension(LXWXH) 4000mmX2200mmX800mm
Curb weight 6000kg
Max payload 10000kg
Painting With shot blasting and 4 layers painting,color is optional.
Drive type Left/right hand drive optional
Drive wheel 4X2
Transmission 6/8 speed forward levers,1 reverse lever.
Axle 2pcs
Tire 9.00-20/6pcs
Cab 3 passengers , with air-conditioner
Front/Rear tread 1750mm/1680mm
Wheelbase 3850mm
Emission Euro 2
Horse power 160-180hp
Braking system Drum
Max speed 90km/h
Fuel type Diesel
Electrical system 24 voltage,7 wire harness.
Light LED type
Remark:
The above mentioned data is for your reference only.
The detailed specification will be subject to our final confirmation.


8 - 10 Tons Utility Dump Truck For City Multipurpose Left / Right Hand Drive Optional

The choice of the dump truck or according to specific purpose to choose the appropriate type, because of the dump truck general work environment are hard, choose the brand with quality and excellent public praise is particularly important, high attendance truck is a good tool to earn money.
