Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
Specifications
Brand Name :
HOWO
Model Number :
ZZ3317N3567
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Truck body material :
Carbon steel, High-strength steel
Truck body shape :
U shape similar VOLVO
Engine power :
371hp STEYR Tech
Loading capacity :
50-60 tons
Gearbox :
12F,2R
Steering :
LHD,RHD
Description

50 - 60 tons SINOTRUK Dump Truck 4 axles HOWO 8x4 strengthened tipper truck

371hp 12 wheels CNHTC HOWO dump truck,8x4 dumper truck

Product features:

1, Oil Saving, Safety, Driving comfort, Reliability, Low application cost
2, Engine, Sinotruk WD615.47, 371HP or 290HP/36HP, German Man technology.
3, Front dumper. dumper body: Square shape or U-shape.
4, dumper body: 20cbm to 30cbm, heavy duty load capacity: 50ton to 60 ton
Floor thickness: 8mm to 14mm, Side wall whickness: 6mm to 12mm for customers' different use
5, Hydraulic system: HYVA brand or Chinese famous brand.

Cabin

HOWO 76 Standard Cab
With two bunks, 70° hydraulically tillable to the front as attached photo for ref.
Vehicle Main Dimensions (L x W x H)mm 11645x2500x3400
Wheel base (mm) 1800+3500+1350
Wheel track (front/rear) (mm) 2022/1830
Approach/Departure angle(°) 19/18
Weight in KGS Tare Weight 15680
Loading Capacity 16010
Front axles loading capacity 2x9000
Rear axles loading capacity 2x16000
Max. driving speed(km/h) 75
Engine Brand Sinotruk
Model WD615.47
Type 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 371HP
Emission standard Euro Ⅱ
Gearbox HW19712 , 12 forwards & 2 reverse
Clutch Reinforced diaphragm clutch, diameter 430mm
Steering Gear ZF 8118,power steering, hydraulic steering with power assistance
Fuel tank (L) 400
Tire 12R22.5 All steel radial tire is available , 12 pieces
Brakes

Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake



dump Body


Thickness

 Side 6mm-12mm in high tensile strength steel Q345/B
Front 6mm-12mm in high tensile strength steel Q345/B
Bottom 8mm-14mm in high tensile strength steel Q345/B
Dump body Size (L x W x H) 7300mm x 2300mm x 1500mm


Tipping hydraulics

 Tipping type Front tipping type
Tipping system Complete set of HYVA brand hydraulics system


Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck
