12 Wheelers 4 Axle Dump Truck , LHD RHD HOWO A7 Strengthened 8x4 Tipper Truck
12 Wheelers 4 Axle Dump Truck , LHD RHD HOWO A7 Strengthened 8x4 Tipper Truck
12 Wheelers 4 Axle Dump Truck , LHD RHD HOWO A7 Strengthened 8x4 Tipper Truck
12 Wheelers 4 Axle Dump Truck , LHD RHD HOWO A7 Strengthened 8x4 Tipper Truck
Specifications
Brand Name :
HOWO
Model Number :
ZZ3317N3567N1
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cabin series :
HOWO A7
Dump truck body :
7m, 7.3m
Driving type :
8x4
Steering type :
LHD, RHD
Wheelers No. :
12 +1
Truck Body material :
Carbon steel, High-strength steel
Description

SINOTRUK 4 axles 12 wheelers 8x4 LHD RHD HOWO A7 Strengthened Tipper Truck

howo a7 dump truck also called selfunloading truck, which operate according to hydraulic pressure or

machinery lift equipment, usually use in civil engineering and work with grab ,shovel

loader ,etc. This type of A7 dumper chassis, which have good appearance and

massive feeling, especially heavy loading capacity and durability, suitable for any

kinds of bad conditions .

A dump truck (or, UK, dumper truck) is a truck used for transporting loose material (such as sand, gravel, or dirt) for construction. In the UK and Australia the term applies to off-road construction plant only,and the road vehicle is known as a tipper, tipper lorry (UK) or tip truck (AU).

Model ZZ3317N3567N1 LHD/RHD
Driving type 8x4
Total mass (kg) 31000
Curb weight (kg) 15200
Dump box dimensions(mm) 7200,7300 x2300 X 1100

Overall dimension(L/W/H)

(mm)

 10360,10410 X 2496 X 3490
Approaching/departure angle 20/23
Wheel base 3525+1350
Max speed(km/h) 78
Cabin A7-W low floor lengthened cab, with one / two sleeper, with A/C.
Engine Horsepower 336HP(247KW) /371HP(273KW)
Model WD615.69 / WD615.47
Fuel Diesel
Emission Standard EURO 2
Displacement (L) 9.726 Liter
Max torque 1350Nm / 1500 at 1100-1600 rpm

Cylinder diameter/

stoke:

 126mm/130mm
Compression ratio 17:1
Rated revolution 2200RPM
Engine net weight 850KG

Full load fuel

consumption

 193g/kw h
Gear box Model HW15710 / hw19710
Speed 10drive, 2reverse
Max torque 1500NM / 1900NM

HW15710/HW19710 SINOTRUK10 speed manual type transmission, the first shift

gear ratio: 14.28. Gear ratio:1=14.28, 2=10.62, 3=7.87, 4=5.88, 5=4.38, 6=3.27,

7=2.43, 8=1.80, 9=1.34, 10=1, R1=13.91, R2=3.18
Steering ZF8098 power steering, hydraulic steering with power assistance.
clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance.
Front axle 2x HF9, 18 ton axle load, rigid stub axle with double T- cross section and dish brake.
Rear axle

2xAC16, AC16 heavy casting hub reduction drive axle, with super loading ability,

excellent performance on start-up with heavy load and slope climbing.

Tire & Rim 11.00R20; 12.00R20; 11.00-20; 12.00-20.
Brake Service brake Dual circuit compressed air brake
Parking brake Spring energy, storage air-break brake
Engine brake Engine exhausted gas brake.
Electric &Equipment Operating voltage 24V negative grounded
Battery voltage 12V/165Ah,cigar lighter
Color White, red, yellow, green, blue
