40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
40 Ton Heavy Duty Dump Truck , 8x4 FAW Tipper Trucks LHD / RHD Power Assistant Steering
Specifications
Brand Name :
FAW
Model Number :
CA3256
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
10 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cabin :
J5P
Driving type :
8x4
Color :
customer request
Capacity :
40 tons
Steering :
Power-assistant, LHD / RHD
dump body size :
20-25 cbm
Description

40 tons 8x4 faw dump truck, 4 axles FAW dump truck, FAW 8x4 dumping truck


FAW front jacking heavy duty dump truck specification


FAW J5P 6×4 dump truck
Drive System 8×4
Overall dimensions (L*W*H) (mm) 9893 × 2494 × 3200
Dump body (L*W*H) (mm) 9500 × 2300 × 1500
Thickness (mm) Bottom 12, side 6
Hydraulic lifting system HYVA hydraulic systerm
Approach / depature angle (° ) 27 / 27
Kerb weight (kg) 14 600
Total mass (kg) 32000
Wheel base (mm) 1800+3500 + 1350
Overhang (mm) (F/R) 1493 / 1650
Track width (mm) (F/R) 1939 / 1860
Engine WD10 380 ( WEICHAI, Euro 2 )
Rated power 380 hp
Gearbox 12JS160T (Fast gear)
Clutch Φ 430mm Diaphragm type
Front Axle 8.5T
Rear Axle 13 Ton , speed ratio 5.286
Tire Tubeless tire 12R22.5
Fuel Tank 315L

Several problems to pay attention to when installing the 40 tons 8x4 FAW Utility Dump Truck, 4 axles FAW dump truck, FAW 8x4 dumping truck

1. The carriage of bulk items must be used with bucket carriages;

2. Special attention should be paid to the height and lifting stability of the carriages when the carriage length is greater than 5.6 meters;

3. It is not possible to transport the earth stone party with the coal transport. General coal vehicle height is 1.6 ~ 1.6 meters, the length of the how this type of vehicle design is a lightweight goods (specific gravity is less than 1.2), used to transport conditions may have problems with lifting poor stability, serious can cause lifting rollover accident;

4. Do not use the shovel carriage to transport the sticky goods such as silt and clay. The structure of the dipper compartment makes the sticky goods more difficult to unload;

5. When selecting a dump truck for iron ore powder, it is necessary to make a statement with the manufacturer to select a carrier for iron ore powder.

6. When used for paving asphalt transportation, the lifting mechanism requires slow lowering device.
