Specifications
Brand Name :
SINOHTC
Model Number :
HTC9401BGZX
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Material :
Steel, High-strength Steel
Axle No. :
3,4
Tyre No. :
12,16
Axle model :
13,16,20 tons
Capacity :
>50 tons
Color :
Red,blue
Description

28 - 38m3 3 axle Dump trailer, tri-axle self dump trailer,80 tons dumpping trailer

Specifications:

Dimension: Length: Approx 12,740 mm
Width: Approx 2,500 mm(including mud guard)
Height: Approx 3,250mm @ unload
King Pin Location: Approx 900mm from the front face of the front bolster
Axle spacer: Approx 7,370 mm+1350mm+1350mm
Landing Gear location: 2,500mm behind the king pin location(no confirm)
Fifth wheel (King Pin) Height: Approx 1,296mm with the chassis level(no confirm)
(The above dimension will be adjusted according to the tractor specification.)
Weight: Tare Weight (Tolerance 0~-4%): Approx 15,900 kg
Max. Payload: Approx 70,000 kg
Gross Vehicle Weight: Approx 85,900 kg
Steel Structure: Material: High strength low alloy steel (350 MPa)is used for welded I-beam and (235MPa) is used for welded fabricated parts.
Carriage box: All welded steel structure, flooring thickness is 4mm steel, Side wall is 4mm, front/back wall thickness is 6mm steel, reinforce with full welded stiffeners.

Our 3 axle Dump trailer have good price with excellent quality, and with our long time experience, we can provide you an satisfied service and experience

28 - 38m3 Semi Dump Trailers High Strength Steel Material Three Axle

1.Made of high strength steel

2.Sprayed with paint of supreme quality, making the semi-trailer good-looking, rot-proof and durable

3.2 axles and 3 axles are available to meet the weight or size of specific objects

4.Applied the most advanced digital control plasma cutting technique, and welded by automatic Submerged-Arc processes

5.Safe,reliable driving and easy maintenance
