60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear
Specifications
Brand Name :
SINOHTC
Model Number :
HTC9407
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Trailer type :
U shape dumping trailer
Trailer model :
Dump trailer train
Axles Qty :
2+2
Axle model :
13,16 TONS
Axle Brand :
FUWA, BPW, L1
Loading capacity :
60tons
Description

2 axles U shape double dump trailer train loading capacity 60 tons

This 2 axles U shape double dump trailer train, special used for road transporting. Usually be used for transport sands, cobblestone and other easy unloading cargo.

Type Side dumping trailer
Tare Weight 7.85T-8.5T
Payload ≤60T ≤37m3
Axle Weight Load 13T/16T per axle
Specification
Axle number 2
Axle specs FUWA /BPW brand
Suspension Mechanical suspensions
King Pin 50#/90#
Dimensions
(LxWxH)		 6500/ 7300×2480/2500×3040mm(Outside)
6300/7100×2270/2300×1500mm(Inner)
Rim 9.00/8.00
Lifting system Four ø125lifting cylinders, or ø140displacement cylinder
Steel Spring 10pieces
Tire
Tire specs 12R22.5-18/11.00R20-18
Number of Tire 12pieces
Spare Tire Carriers 1/2 pieces
Frame: (specs. and materials) Main frame is height 450/500mm ,.
Frame Beam Upper plate is 14mm,lower plate is14/16mm,middle is8/10mm side beam is 16# U-steel. left side:3 or 4 pcs French door; Right side:3 or 4 pcs hanging door.With19 pcs lock bar.
Frame Floor The Thickness is 3mm flat bed
Brake Three double chamber
Electrical 24V 7 ways(7 wire harness)
Light color
Side marker lamp Orange
Rear lamp Red
Turn signal lamp Orange
Landing gear 28T
Miscellaneous
Painting Accordingly
Tools box One pieces or According to the buyer

60 Ton Double Axle Dump Trailer 13 / 16 Ton Axle Model 28T Landing Gear

Quick Details

Use: Transport bulk dry powder or sands Type: Tipping Semi-Trailer

Material: Steel Certification: SGS / ISO / BV / CQC / CCC

Size: Single 6500/ 7300×2480/2500×3040mm(Outside)
6300/7100×2270/2300×1500mm(Inner) (as needed)

Max Payload:60T (Trailer train)

Place of Origin:Shandong, China (Mainland)

Brand Name:SINOHTC

color:as needed

logo:as needed

design:as needed

OEM:accepted

customizing:accepted

3rd party inspection:accepted

brand of axles:FUWA / BPW / others

paint: anti-rust process
