25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
25m3 6x4 Cement Tanker Truck , Strong Carbon Steel Tank Cement Carrier Truck
Specifications
Brand Name :
HOWO
Model Number :
ZZ5257GFL
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
10 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Tank material :
Carbon steel
Tank volume :
20-35m3
Driving type :
6x4, 8x4
Cabin :
HOWO76, HOWO A7
Color :
Red, blue, orange, white
Steering :
Power-assistant, LHD/ RHD
Description

25m3 Cement truck / Concrete truck , Bulk cement truck , Cement tank truck

This 25m3 6x4 Bulk cement truck special for Transporting Bulk Cement Powder. Loading capacity more than 30 tons. The tank volume as your request, could be 20m3, 22m3, 25m3. If you want 30m3, 35m3, also could be mounted 8x4 truck chassis.


Specifications:

Item
Chassis HOWO
Engine SINOTRUK, WD615.47
Emission Euro II
Rated Power 273kw
Displacement 9726ml
Gearbox 10/12 speed
Tire and spare tire 12.00
Cabin HW76 Flat roof cabin
Axle Front axle:9T / Rear axle:16T
Wheel base 4600/ 5100+1350 mm
Dimensions 10150/ 10880×2462×3450 mm
Oil cylinder MSGK01-90/50×670E
Vacuum pump 50QZ XDH-68/7000×2 Max. Vacuum level 93-96 KPA
Oil pump CB50 Right X2 Effective suction distance ≥7-20m
Multiple valve 2TS1-L10C-T/20 Mileage 68L/S
Oil pressure gauge X-60-16MPa Power 5kw
Power takeoff Dedicated Absolute Pressure 7Kpa
Safety valve ZG1.5A27W-10-03
Tank Material Q235B (carbon steel)
Tank thickness 6mm
End Socket Thickness 6mm
Tank Capacity 25 m3
Total Mass 44900 kg
Kerb Mass 17715 kg
Payload 25990 kg
Oil Paint Metallic paint
Functions The main functions are to suck out and transport stool, sludge, stones and other liquids with larger suspension solids for urban service department, particularly suitable for pumping, loading and discharging sediment in the sewer, especially it can suck out bigger objects such as the stones and bricks in sewer.

Cabin - World Famous Tech

Model : HW76 model, With one sleeper,Technology,Up and down, left and right sides Adjustable steering wheel,European new type heater as a whole,German (V-DO) instrument,Four full floating suspension + suspension device,Double locking structure belts.

Engine - WD Series

Diesel:4-stroke direct injection diesel engine
Model:WD615.47, 371hp, Euro II emission standard 6-cylinder in-line with watercooling,turbo-charging and intercooling,4 strokes
Maximum output: 371hp(273kw)at 1900rpm
Number of cylinder:6
Displacement:9.726L Bore/Stroke:126/130mm

Gearbox - HW Series

Model:HW19710,10F/2R,Manual Gearbox
MAX.Input Torque:1900NM
Deputy box structure of planetary gear

HC16 Drive Axle

Model:HC16(Tandem syetem) Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle
Rated load : 2×16000 Kg
Spring gage : 1020 mm
Wheel tread : 1850 mm
Input flange : Ф180
Differential device : Inter-wheel and inter-axle
Wheel bolt : Ф335-10×M22×1.5 mm
Min rim size : 20 inch
Lubricants : GL5 85W-90

Our Product Advantages


(1) Competitive Factory Price and Excellent Quality
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.
(3) Products Quality Certification SGS CCC ISO
(4) Perfect after-sale service
(5) Customized products available with us
(6) Export to more than 30 countries and regions
(7) One year quality guarantee or within 100000km, which comes first.
(8) Other spare part could be supplied by OEM at cost prices.
(9) Regularly callback to know the vehicle's working status.
(10) The overseas engineers are always ready to deal with unexpected needs.
