FAW 40m3 Bulk Cement Truck 2 / 3 Seat J5P With A/C Cabin 8X4 Driving Type
FAW 40m3 Bulk Cement Truck 2 / 3 Seat J5P With A/C Cabin 8X4 Driving Type
FAW 40m3 Bulk Cement Truck 2 / 3 Seat J5P With A/C Cabin 8X4 Driving Type
FAW 40m3 Bulk Cement Truck 2 / 3 Seat J5P With A/C Cabin 8X4 Driving Type
Specifications
Brand Name :
FAW
Model Number :
CA1310P2K2L7T4EA80
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cabin type :
Low-roof, High-roof
Seat :
2,3
Engine brand :
WEICHAI , FAW XICHAI
Engine emission :
Euro 2, 3,4,5
Capacity :
40m3
Tank material :
Carbon steel
Description

8 x 4 FAW 40m3 dry bulk power tank truck transporting powder material

The 40m3 dry bulk powder tank truck special for transporting charcoal dust and other low density dry bulk powder material.

The followed is truck chassis specification:

Type: CA1310P2K2L7T4EA80
Cabin: J5P with A/C
Engine Model: WP10.336NE31.
Emission standard: Euro 3.
Clutch model: 430mm, single plate, dry, diaphragm
Gearbox Model: FULLER 12JS160T transmission
Rear Axle: LB300 wheel reduction axle
Rear Axle speed ratio: 5.26
Wheel & tire: 12.00R20, Model 18Ply
Axle Base: 1860+4660+1350
Fuel Tank: 300L,

Overall dimensions Length: 11993mm
Width 2499mm
Height 3330mm
Front overhang(loaded) 1840
Rear overhang(loaded) 1840.

Wheel base Front wheel 2020
Rear wheel 2020
Passing angle(loaded) Approach angle 24
Departure angle 22

Mass
Parameter Curb weight (kg) 17805
Gross truck weight 31000
Capacity of tank: 40 m3
Length of tank: 9600mm
Diameter of tank: 2500mm.

Item unit parameter
Vehicle model HTC5310GFLC3
Chassis model CA1313P7K1L11T4E
Overall dimensions mm 11980*2500*3950
Tank volume L 34900
Wheel base mm 1900+4500+1350
F/R track base 1375/2855
Approach/departure angle 40/20
Exhaust/hp ml/hp 23/9
Max speed km/h 80
Tire specification 12.00-20 Engine type CA6DL1-33E3/ WP10.340E32
Traction system 8*4 transmission 9-speed with over drive
Number of axles 4 Electric system 24v
Operation control system Electrically hydraulic control Allowable passengers in cab 3
Instruction

Meterial:6mm carbon steel.

Discharging Hose, 4 inch

Discharging Hose Length ,6,000 mm

Discharging capacity≥1,200 Kg/min

Working pressure,0.2 Mpa.

MAX Horizontal Discharging Distance, 5,000 mm

MAX. Vertical Discharging Distance,25,000 mm.

Air Compressor , WB-10/2, Made in China,8M³
Engine FAW/ WEICHAI diesel engine (Europe 3 emission standard)
Production cycle 25-30 days
