8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
Specifications
Brand Name :
FAW
Model Number :
CA1169XXYLC
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Truck type :
refrigerator truck, refrigerated van truck
For Transporting :
Frozen meat, fish, icecream
Temp. ranger :
-18, -45
Thickness of plate :
103mm, 83mm
Loading capacity :
8-10 tons
Steering :
LHD,RHD
Description

8 - 12 Tons FAW 4 x 2 refrigerator truck 6 wheels closed van truck

Real benefits for the customers

1, working ambient temp.width, van box truck can work very well during -25*C to +55*C ambient temperature,and the the temperature in container can lower to -20*C,keep the safe transportation under any condition.
2, Very easy be installed and operation, digital contrller in cab,easy be setting and check.
3, High quanlity Maintence parts provide in time ,exactly

Rapidly lower the temp. Reach the setting temperature rapidly,can save 20% time to pre-cold the container,after the cargo drop,can quick back to the setting temperature.

Precision Temp.control, very stable performance, keep the container temperature fluctuation within +/- 1*C,keep the cargo in ideal temperature all the way!

Description FAW commercial refrigerated trucks /4X2 FAW Refrigerator Trucks/180HP 220HP Refrigerator Trucks
Drive Model 4X2
Vehicle Main Dimensions (L x W x H)mm 9990X2490X3850
Wheel base (mm) 4770
Wheel track (front/rear) (mm) 1880/1800
Weight in KGS Tare Weight 16000
Loading Capacity 10000
Max. driving speed(km/h) 85
Engine Model CA6DF-18E3, CA6110-125Z
Type 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 180HP/ 170HP/ 210HP
Displacement 6.74L
Max Output Power 132KW
Emission standard Euro III
Gearbox CA6DM75 6forwards& 1 reverse
Clutch Reinforced diaphragm clutch, diameter 420mm
Tire 9.00-20,9.00R20, 6pc including 1 spare tire
Brakes Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Steering Gear power steering, hydraulic steering with power assistance
Refrigerator Box Equipment
Box dimension 7400X2280X2400mm
Van Material GRP/Steel/Aluminum Alloy in the surface, foam in the middle, thickness 80-100mm
Temperature -20-0 Celsius
Brand Chinese/US/Korean refrigerator for option
Application Seafood, Fish, Ice Cream, Meat and other need cooling food.

8 - 12 Tons Refrigerated Box Truck , 6 Wheels 4x2 Drive Freezer Box Truck
