4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
Specifications
Brand Name :
HOWO
Model Number :
ZZ1073SCD
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Truck TYpe :
Truck Mounted Crane
Crane lifting :
2,3,4,5,6,8 tons
Truck loading :
3,5,8,10,12,15 tons
Color :
According your request
Crane brand :
XCMG, HIRB
Steering :
LHD,RHD
Description

4x2 HOWO 5 tons Truck Chassis mounted 3 tons crane 10 tons truck mounted 8 tons crane

small truck crane ,also called boom truck crane,mobile truck crane , truck mounted crane , hydraulic folding truck crane,telescopic straight boom crane,truck with crane , crane lorry,hydraulic arm crane for trucks,pickup truck mounted crane,light truck with crane,folding arm hydraulic lift platform,hydraulic crane telescopic boom,mobile crane price ,self loader truck with boom crane,new forland lorry truck mounted crane,telescopic boom truck mounted crane,flatbed knuckle boom truck crane,6 wheelers truck with crane boom truck cranes sale etc

A crane mounted on a truck carrier provides the mobility for this type of crane. This crane has two parts: the carrier, often referred to as the Lower, and the lifting component which includes the boom, referred to as the Upper. These are mated together through a turntable, allowing the upper to swing from side to side. These modern hydraulic truck cranes are usually single-engine machines, with the same engine powering the undercarriage and the crane. The upper isusually powered via hydraulics run through the turntable from the pump mounted on the lower. In older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the crane down the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turntable of aging newer design cranes.

TRUCK MOUNTED CRANE
# Descriptions Specifications and types

General

 Truck Brand SINOHTC (our brand)
Chassis Brand Sinotruk howo
Approx. Dimension 5995*2250*3200 mm
GVW./Kerb Wt. 4495/ 2805kg

Cab

 Cab Capacity 3 persons' seat
Air Conditioner Air Conditioner is optional

Chassis

 Drive Type 4X2,LHD or RHD
Fuel Type Diesel
Engine Make & Model Chaochai engine
Power 120hp-140hp
Emission Standard Euro II or EURO III or EURO IV
Brake Air Brake
Wheelbase/No.of axle 3300 3800 mm / 2
Tyre Specfication 7.50-16
Tyre Number 6 tyres and 1 spare tyre
Max Speed 80 km/h
Paint Automative metallic paint
Cargo box Cargo body dimension 3400*2200*600 mm

Crane

 Max Lifting Capacity 2000kg /3200 kg /4000kg/5000kg
Installation Space 550-850mm
Structure& Function

Telescopic/Articulated boom crane loading weight:2T,3.2T,4T,5T,

6.3T,8T,10T,12T,14T,16T,20T 25T or others

Truck Cargo length: 3m-13m.

Crane Brand optional: XCMG,HIRB or others.

Crane Installation Site: Rear or Middle part

4x2 HOWO Cargo Transport Truck Chassis Truck Mounted Crane 120 - 140hp Power
