Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Brand New Concrete Transport Truck WD615 STR Engine 8m3 Cement Mixer Truck
Specifications
Brand Name :
HOWO
Model Number :
ZZ5257GJB
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Truck type :
Concrete mixer truck
Driving type :
6x4, 8x4
Steering :
LHD,RHD
Color :
White/ Blue
Truck condition :
Brand new
Used for :
Mixer concrete
Description

8 / 9 / 10 / 12m3 Concrete mixer truck / Cement mixer truck , HOWO Concrete Drum truck

Product Introduction:

1. Based on STR technology from Austria
2. Cabin:Four point s suspension HOWO Cabin with spring and air shock absorber, VDO panel
3. Engine:371HP WD615 STR engine ( from 290hp - 420 hp you can chose )
4. Front axle: HF9 STEYR technology front steering axle
5. Rear axle: HC 16ton STEYR technology double reduction hub reductor driving axle
6. Steering: ZF8198, driver sit at the left hand side
7. Loading capacity: More than 30ton
8. Designed for tough road condition especially for African countries
9. Excellent spare parts supply for after-sales service.

Specifications:

Model ZZ1257N3841W
Dimension(L×W×H)(mm) 10560×2496×3748

agitator tank		 10m3,ARK,,TOP,,5mm,3-5mm,8+4mm.
10m3,ARK pumps, motors, TOP speed reducer are imported Italian.Thickness of the tank: 5mm,Thickness of blade: 3-5mm Wear-resisting corrosion resistant plate.Double head tops:8+4mm
Curb weight(kg) 10580
Rated weight(kg) 14290
Wheel base(mm) 3825+1350
Approaching/Departure Angle(°) 16/24
Front/Rear overhang(mm) 1500/1885,1860
Max speed(km/h) 102
Front axle HF9 drum brake
Rear axle HC16 Radio 4.8

Engine		 Model WD615.47 371HP
Displacement(L) 9.726/Diesel
Emission EURO 2
Transmission HW1910,10F, 2R, manual operated
Tank dimension(L) 400L
Driving steering ZF8118, Right driving
Cab HW76 long cab,single sleepers,with A&C
Tire 12.00R20 (10+1)
Mixing Drum
Mixing volume 8m3 9m3 10m3 12m3
Geometrical area(m3) 13.94 15.18 17.9 20.5
Effective Mixing
Volume(m3)		 9 10 12 14
Mixing Capacity(m3) 5 5 5 5
Drum Inner Max
Diameter(mm)		 2300 2300 2400 2400
Drum Length(mm) 4750 5039 5474 6069
Angle of Inclination 13 13 12 10.8
Mixing speed(r/min) 0-14 0-14 0-14 0-14
Slump(mm) 40-210 40-210 40-210 40-210
Hydraulic system
Oil pump type
/Max working pressure		 REXROTH/EATON/SAUER
42*90 42*90 42*90 41.5*105.5
Motor type
/Max working pressure		 REXROTH/EATON/SAUER
42*80 42*80 42*80 41.5*105.5
Gear Reducer type
/Max working torque
/speed ratio		 PMP/SAUER/TOP/BONFIGLIOLI
60000/99.9 60000/102.8 65000/120.3 75000/129.94
Oil cooler type/Volume FLJ-9X YLF-201A
18
Water supply system
Water supply Mode Compressed Air Mode
Water Tank Capacity(L) 450
