50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments
Specifications
Brand Name :
SINOHTC
Model Number :
HTC9404GYYTG
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
Western Union, L/C, T/T, MoneyGram
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Tank Material :
Steel,stainless,aluminum
Compartments of tank :
6
ABS :
fitted
HS Code :
8716311000
vapor recovery :
fitted
suspension :
mechanical leaf spring
application :
fuel,diesel,petrol,gasoline oil
function :
fuel oil road transportation
Description

50m3 4alxe fuel Tank semi trailer, four axle fuel Tanker trailer diesel,petrol,gasoline oil tanker trailer

our fuel Tanker trailer, you can make 40 000 - 55 000 liters Oil tanker, 5 or more compartments,stainless or aluminum tanker material


Specifications:

Tank Body
Shape Optional (Round or Square)
Dimension 12500mm*2490mm*3990mm
Tare Weight About 9600Kg
Total Volume(m3) 50.0 m3
Tanker Body Material 5mm or 6mm /Q235 carbon steel
End Plate 5mm or 6mm/Q235 carbon steel
Manhole Cover Carbon steel or Aluminum alloy API manhole cover ,500mm
Bottom Volume Aluminum API Pneumatic Bottom Valve
Discharging Valve Diameter is 3 or 4 inch
Compartments 5 isolated compartments, Optional
Discharging Pipe 4" rubber hose,2 pcs,6m/each
Cat Walk With (Common model or special design)
Chassis
Main Beams Welding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material
Axle 4 axles, BPW/FUWA/JINSHENG brand
Landing Gear JOSTD200T or China brand 28T
King Pin JOST 2.00 OR 3.5 inch bolt-in king pin
Suspension Mechanical suspension(Germany or American type)/air suspension
Leaf spring 90mm*130mm*10 or 100mm*12mm*12
Pneumatic Braking System WABCO RE 6 relay valve; Spring brake chamber
Rim 9.00-22.5/8.00-20/8.5-20 China brand
Tire 12R22.5;315/ 80R22.5;11.00R20;12.00R20;
No. of the Tire 16
ABS Optional
Painting Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint
Accessories One standard toolbox

50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments

50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments

We are the full-size Modified Truck enterprise which integrate the design of product scientific research developing, production and sale together.

Along with the development of Hetanch truck and trailer manufacture, we dedicate to improve the quality of our products and try our best to provide customers with good cost and performance products.

In regards to manufacturing persisting the principle of "Best quality, Competitive price, Sincere Service."
