13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
Specifications
Brand Name :
SINOHTC
Model Number :
HTC9402RVX1
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
Western Union, MoneyGram, L/C, T/T
Supply Ability :
100 UNITS PER MONTH
Delivery Time :
40 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Materail :
FRP+PU+ Aluminum
Certificate. :
ECE,GCC,CE, ISO9001, DOT, CCC, ISO/TS16949, Adr
Capacity :
>40 tons
Tire Model :
315/80R22.5
Color :
customer request
suspension :
Air suspension
Description

13m 40ft Food Refrigerated container Trailers,Refrigerator / Freezing container Trailer

40ft Food refrigerated enclosed trailer
Products Parameters

Dimension:L*W*H 12980 * 2500 * 3420,
Landing leg setting 2640(mm)
Kingpin plate height 1203(mm)
Axle Space 7130mm+1310+1310,6830+1310+1310,6530+1310+1310
Tare Weight 8600kg
Payload 42000kg,
G.V.W.R 50 000kg
Landing Gear /two-sides operation
Kingpin 3.5"welding type
Brake system Dual line pneumatic brake system
ABS yes
Brake Chamber Type 30/30 spring brake chamber
Axle FUWA axle ,13 ton capactiy/ set, 3pcs
Tire 315/65r22.5,385/65r22.5,425/65r22.5
Rim 8.5*22.5,9.0*22.5
Main beam 500/10/5/12
Tool box 2.5m/1
Spare Tire Carrier two
refrigeretor unit Thermo king or Carrier

Food storage box ,fire extinguisher / cupboard , water tank , fuel tank ,quarter type mudguards ,wheel chocks , double spare wheel holder ,foldable rear ladder , cooling unit access ladder

ECE regulation No :104 -Side panels with white color , rear side of the vehicle marked with red color reflective band

80 mm thick GRP floor top on 24 mm resin coated birch plywood planks permissible fork-lift axle load of 5.460kg according to DIN EN 283

Sides, front wall and roof made of one Single piece insulated polyurethane sandwich panels covered on inner sides with 2 mm outer side with 3 mm FRP. (Color is white)

Front , back and roof wall thickness is of 90 mm, Floor wall thickness is of 105 mm , side wall thickness is 65 mm.

The rear door is a two piece construction with stainless steel frame; each door is fitted with 4 stainless steel hinges on either side, external-locking assembly. All doors are provided with rubber flap type seals.

13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer

13m 40 Ft Refrigerated Trailer , Air Suspension Refrigerated Enclosed Trailer
