Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type
Specifications
Brand Name :
FAW
Model Number :
CA3120P9A80
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Color :
White, yellow
Steering :
LHD,RHD
Gearbox :
6,7,8 forward
Wheels No. :
6+1
Capacity :
7 tons
HS Code :
8704239000
Description

2 axles 4x2 Light Duty Dump Trucks 7 tons , LHD / RHD Tipper truck FAW , Utility Dump truck

This 7 tons 4x2 Utility Light Duty Dump Truck honor produced by FAW. It's 6 wheels medium duty dump truck.The six wheel dump truck is now a more common self-unloading car, which can be seen in many engineering projects. Because of its stable performance, good safety, relatively cheap price, and good performance in terms of energy consumption, it is always seen that this is a highly cost-effective dump truck. It is capable of large and medium-sized transportation needs in capacity, and can adapt to the transportation task requirements of engineering projects. In the future development, the car will continue to invest in the technical research and development force, which can provide more reliable guarantee and support for construction transportation.

Followed Our Product Advantages


(1) Competitive Factory Price and Excellent Quality
(2) Perfect after-sale service
(3) Export to more than 30 countries and regions
(4) One year quality guarantee or within 30000km, which comes first.
(5) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.

Specification of Dumper truck


Vehicle Description
Type Dump truck Overall Dimensions(mm) 7405*2495*3060
GVW(kg) 11995 Mass in working order(kg) 5850
Design Loading Weight(kg) 6950 Max speed(Km/h) 80
Chassis Description
Chassis Model CA3120 Number of axles 2
Cab FAW Allowable Passengers In Cab 3
Wheel base(mm) 4090 F/R track base(mm) 1965/1860
F/R overhang(mm) 1420/1985 Approach/Departure angle(°) 25/20
Spring plate 10/10+9 F/R axle-load 4200/7795
Tire specification 9.00-20 Tire quantity 6+1
Air conditioner Optional Type of fuel Diesel
Braking system Air braking Electric system 24V
Traction system 4*2 Operation control system Steering Wheel
Engine Description
Engine model CA6110-125 Engine manufacture FAW WUXI Diesel Engine Co., LTD
Exhaust(ml) 4170 Horse power 180/210
Up-parts Description
Cargo body dimensions(mm) 4300*2300*800
Cargo body material Carbon steel Q235
Lifting system Equipped with middle hydraulic system
Optional Configuration
Van thickness,side door,and other china brands hydraulic cylinder,etc.
