Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type
Specifications
Brand Name :
FAW
Model Number :
CA3310T4
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Cpacity :
40-50 tons
Steering :
Power-assistant, LHD/ RHD
Cabin :
New J5P Low roof
Driving type :
8x4
Engine :
STEYR WEICHAI 340HP/ 380HP
Color :
White, yellow
Description

4 axle 8x4 Dump truck / Tipper truck , 12 wheels FAW Tipper truck , haulaging dump truck

This 12 wheeler dump truck heavy duty could haulaging more than 50 tons. FAW, means First Automobile Works of China. It's named by Chair Mao Zedong in 1956. It's the earliest truck manufacturer in China. FAW group is the biggest vehicle company in China. We, QINGDAO HETANCH TRUCK CO.,LTD belong to FAW Group too.

Specifications:

OVERALL SIZE(mm) 10480*2500*3600 GVW(Kg) 51000
CARGO SIZE(mm) 7200/7400× 2300× 1500 FACT LOADING(Kg) 40t-50t
APPROACH/DEPARTURE 24/16 CURB WEIGHT(Kg) 15300
F/R OVERHAND(mm) 1470/2120 MAX SPEED(km/h) 85
CHASSIS MODEL CA3310P66K2L6BT4E
ENGINE TYPE ENGINE MANAFACTURE CC(ML) POWER(KW)
WP10.380E32 WEICHAI POWER 9726 279
FUEL DIESEL EMISSION GB3847-2005, GB17691-2005 EURO 3
AXLE 4 TIRE 12+1
WHEELBASE 1860+4300+1350 TIRE SPE. 11.00R20, 12.00R20, 11.00-20, 12.00-20
AXLE LOADING 6500/6500/18000 F TRACK 2050/2050
STEEL SPRING PLAT 10/10/12 R TRACK 1830/1830

Product Description:

FAW 40-50 Tons Dump truck
Overall dimensions Length 10488
Width: 2500
Height: 3185, 3480
Axle base (full load): 1860+3960+1350
Front overhang(loaded): 1438
Rear overhang(loaded): 1880

Wheel base Front wheel: 2020
Rear wheel: 1840.
Ground clearance(loaded) Under front axle: 285
Under rear axle: 290
Passing angle(loaded) Approach angle: 24
Departure angle: 39
Mass
Parameter Curb weight (kg): 15725
Gross truck weight: 31000
Payload weight(kg): 15080
ENGINE: WP10.336N, WP10.340E32
TRANSMISSION: CA10T, FULLER 12JS160T
REAR AXLE: LB300
TIRE: 12.00R20
Cargo box dimension: 7200/7400X2300X1500mm

Haulaging Port Bulk Cargo Heavy Duty Dump Truck 50 Ton Loading 8x4 Driving Type

These trucks produced for CRCC. Used in Pakistan for buliding railway.
