U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
Specifications
Brand Name :
SINOHTC
Model Number :
HTC60MPX
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, , T/T, Western Union, MoneyGram
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
50 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
type :
U shape rigid dump truck
area :
mining site
Capacity :
>60 tons
Engine :
420HP
transmission :
manual
Steering :
Power-assistant, LHD/ RHD
dump body :
5600x2800x1500MM
cab :
single side cab
Axles No :
3 axles
Description

3 axles 50-60 ton Rigid U shape Mining Dump Truck, U shape rigid dump Truck,mining dumper

This Mining Dump Truck is popular in Africa, South-east Asia, especially in the mining site, it have very good performance.

specification

Truck Model: HTC60M
Driver Cabin: SINGLE CAB
Engine/horsepower: WP12.420
Gearbox: 12JS200T
Steering: ZF8118
Front/Rear Axle: 16T / 25T double reduction axle
Chassis frame: mm , 450*130(16+14)
Tipper body dimension(mm): 5800*2800*1500
tipper body Description: Floor 16 side10mm Mn steel ,HYVA 196 cylinder
Other specification: 14.00-24 28PR mining tire
Front/Rear Overhang : Mechanical spring
Front/Rear Axle Leaf Spring 100*20*13,120*32*13
Brake system: Dongjiang brand
others: Three level air filter, exhaust break
Tare weight(kg): 28000
Max weight(kg) 32000
Gross weight(kg): 60000
Overall Dimension(mm): 8800*3200*4100
Max speed(km/h): 51
Min. Ground Clearance(mm): 435
Min turning Radius(m): ≤10
Max grade ability(%): 41
Approach/Departure(°): 33/45
Wheelbase(mm): 3750+1690
Wheel track front /rear (mm): 2793, 2580
Max torque(Nm)/rotate speed(r/min): 2100/1150-1350
Fuel tank(L): 400L

U Shape Rigid Dump Truck , Single Side Cab 50 - 60 Ton Heavy Dump Truck
