GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
Specifications
Brand Name :
SINOTRUK
Model Number :
ZZ5707
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Truck type :
Mining dump truck
GVW :
70Tons
Special used :
Mining site
Tire model :
13.00, 14.00-24
Engine :
STEYR Tech, 336/371hp
Gearbox :
10F,2R
Axle No :
3
Description

3 axle GVW 60 Tons 6x4 Heavy Duty Truck Strengthened Mining Dump Truck

Quick Details for the GVW 60 Tons 6x4 Heavy Duty Truck Strengthened Mining Dump Truck

Drive Wheel: 6x4 Capacity (Load): 51 - 60t

Horsepower:336 - 371hp Condition: New

Transmission Type: Manual Emission Standard: Euro 2

Fuel Type: Diesel Engine Capacity: 9.726 L

Place of Origin: Shandong,China Brand Name: SINOTRUK HOVA

Model mining dump truck
Engine Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.
Model: 336HP/247KW STEYR technology(CNHTC)
Displacement(L): 9.726liter (Euro II standard)
Max torque: 1350NM@1100-1600rpm
Bore/stoke: 126mm/130mm
Fuel consumption: <193g /kwh
Gear box CNHTC Max torque:1900NM
Model: HW19710
Speed: 10speed,2 reverse
Axle(front/rear)
Front axle HW technology front steering axle
Tandem AC16 STEYR technology double reduction hub reductor driving axle
Clutch D430 diaphragm type clutch
Brake Service brake: Dual lines air brake
Parking brake: Spring-Power drum brake
Engine brake: Engine exhaust brake(EVB)
Steering ZF8118, driver sit at the left hand side
Electric Equipment
Operating voltage: 24Vnegative grounded
Starter: 24V,5.4KW
Alternator 28V,758W
Battery voltage 12V/135Ah,cigar lighter
Frame Strengthen steel frame, designed according to tough road condition.
Tyre 10+1 spare tyre with rim
13.00-24
Suspension system: Strongthen heavy duty Leaf spring type
Dump body:
Inside size of Body(mm): 5100x2800x1500 ,12x8mm, made of high intensity steel
Lifting type:Front lifter type HYVA hydraulic system
Overall dimension(mm): 7760x3000x3425(Length x Width x Height)
Wheelbase 3400+1400mm
Track:
Approach/Departure angle 25/32.5
Front /Rear overhang 1500/1560
Max speed 69km/h
Kerb weight: 18415kg
Oil tank capacity 400L fuel tank
GVW 60 ton dump truck , 6x4 Strengthened heavy tipper trucks for Mining site
