6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
6x4 Driving Mining Dump Truck , Heavy Duty 6x4 Tipper Truck 371hp / 420hp Engine Power
Specifications
Brand Name :
SINOTRUK
Model Number :
ZZ5707KY
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Brand :
SINOTRUK HOVA
Engine power :
371hp,420hp
Gearbox type :
Manual
Tyre model :
14.00-24
GVW :
70Tons
Special used :
Mining site
Description

3 axle SINOTRUK HOVA Mining Dump Truck 6x4 driving Heavy Duty Tipper Truck

HOVA mine overload, the truck has an existing design idea .dump design it is entirely new model which according to the characteristics of the mining condition, it is suitable for severe applications such as strip mine, reclamation, steel works, construction site of hydropower station and dock. Engaged in the area of short distance transport business, belonging to non-announcement vehicles model.

Sinotruck power engine, powerful, and reliability. New materials, new structures engine flywheel and engine rear Suspension.

Model ZZ5507S3640AJ (371HP)
Drive Type 6x4 Left Hand Drive
Cab Type HW7D, HOWO CABIN
Equipment

With Air Condition,

HOWO TYPE INSTRUMENT DESK
Weight Kerb mass(kg) 11000
GVW(kg) 11000+40000
LxWxH mm 8334x3000x3570
Dimensions Max. length(mm) 8334
Max. width(mm) 3000
Max. height(mm) 3570
Front/Rear overhang(chassis) 1500/1400
Wheel base(mm) 3600+1500
Track width(mm) 2045/1800
LxWxH (mm) 5600x2800x1600
Body size Length (mm) 5600
Width (mm) 2800
Height (mm) 1600
Steel (mm) Floor 12, side 8
Tipping type Front tipping Hydraulic System, Holland technology
Performance Max. speed (km/h) 70±10
Max. gradeability(%) 50
Approach/Departure angel(°) 20/40
Engine Brand Sinotruk
Model WD615.47 water-cooled,four strokes,6 cylinders in line with water cooling , directly injection
Power (kw/hp) 275kw/371hp
Max torque (N.M)/rpm 1450/1400--1600
Displacement (L) 9.726
Emission Standards Euro 2
Specific fuel consumption 192g/kwh
Transmission Brand SINOTRUK
Model HW19710
Control type Manual
Gear Shift 10-forward &2-reverse speeds
Clutch Type Single plate,diaphragm spring
Diameter (mm) Φ430
Action Hydraulically operating with air assistance
Brakes Type Drum
Service Brake With dual-circuit compressed air brake
Park Brake Power spring brake acting on rear wheel
Auxiliary Brake WEVB
Brand WABCO SYSTERM
Steering Type ZF8098
ZF TECHNOLOGY ZF8098 hydraulic steering with power assistance
Chassis Type Ladder structure with parallel straight
Dimensions (mm) 300x80x8
Suspension Front

Reinforced front vertical semi-ellipse leaf spring,

drum shock absorber, front stabilizing bar
Rear

Reinforced rear integrated balanced suspension,

single side tilt 4 riding screws, rear stabilizing bar

Axles

Front HF10 TYPE: 10 ton axle
Rear

AC16 TYPE: 16 ton strengthened axle,

double reduction driving axle with inter-wheel differential and differential lock
Ratio 6.5
Tyre Type 14.00-20 bias tire
Number 10+1
Fuel tank Tank capacity(L) 500
Material Aluminum alloy
Electrics Type 24V
Starter 5.58kw(24)
Generator 2.0kw(28V 70A)
Battery 2x180Ah
