40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
Specifications
Brand Name :
SINOHTC
Model Number :
HTC9401FLWL
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Material :
Carbon steel, Q345
Axle No. :
3 axle, 2,4 optional
Tyre No. :
6, 12
ABS Braking :
Optional
Tank Volume :
40m3
Independent Engine :
4105
Description

40m3 Tanker bulk cement tank trailer truck for powder transport

Functions :

1. This series tank semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as fuel oil or liquid transporting
2. The volume varies widely from 35 cubic meters to 60 cubic meters, we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs .

Tank Body
Shape Optional ( One Silo with V type or Two ,Three Silos Design)
Dimension 12000mm*2490mm*3990mm ( Exact size depends on the final design)
Tare weight About 7500KGS-15000KGS
Total Volume(m3) 25m³-68 m³
Tanker Body Material 5mm or 6mm/ Q235 carbon steel
End Plate 5mm or 6mm /Q235 carbon steel
Diesel Engine China's brand
Compressor BOHAI 10m³/12 m³or other brand
Manhole Cover Carbon steel or Aluminum 500mm
Discharging Valve Diameter is 3 or 4 inch (Material: Aluminum )
Discharging Pipe 3 or 4 inch rubber hose, 1pcs, 6m/each
Cat Walk With (Common model or special design)
Chassis
Main Beams Welding Design ,Q345 carbon steel
Axle 2 or 3 axles, 12T/13T/16T, BPW/FUWA/HUAJING brand
Landing Gear JOST (D200T)or CHINA BRAND 28T
King Pin JOST 2.00 or 3.5 inch bolt-in king pin
Suspension Mechanical suspension/Germany or America type /Air Suspension
Leaf Spring 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
Pneumatic Braking System WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tanks.
Rim 9.00-22.5/8.00-20/8.5-20 China Brand
Tire 12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional
ABS Optional
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories One standard tool box
Shipping Terms By Bulk Cargo ,RORO

40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer
