2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
2 Tons 2 Axles 2WD Light Duty Dump Trucks For Municipal Construction Purpose
Specifications
Brand Name :
FAW
Model Number :
3036DF5TV
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
4 UNITS IN ONE 40HQ Container
Used for :
Municipal construction dump truck
Wheelbase :
3260,3560
Tyre model :
6.00R15,
Steering :
LHD,
engine :
diesel
engine capacity :
4000CC
Description

2 tons 2 axles 3m3 municipal construction purpose dump truck,2WD mini dump truck


2 tonne tipper truck details specification

Technology data
Model :3036DF5TV
Dismensions
Overall length(mm)4530
Overall width(mm)1750
Overall height(mm)2050
Cargo box length (mm)2540
Cargo box width (mm)1580
Cargo box height(mm)440
/Front/rear overhang(mm)920/1110
Wheel base(mm)2500
Engine
ModelLL485BZL
Type4 cyl. In line water cooled
Power(kw)48/3200
Torque(Nm/rpm)170/2200
Compression ratio18:1
Cylinder bore/Piston(mm)85*95
Displacement(L)2.256
Suspension
Front suspensionRigid housing axle leaf spring type3 pieces
Rear suspensionRigid housing axle leaf spring type8+4 pieces
Transmission
Model5+1 synchromesh transmission
TypeManual Mechanical
Speed ratioI:4.696
II:2.536
III:1.576
IV:1
V:0.856
R:4.174
Steering
TypeRoller type
Clutch
TypeSingle plate, dry type
Front brake SystemTwo section hydraulic drum
Rear brake SystemTwo section hydraulic drum
Tires
Type6.00-14/6
Safe
Safe beltThree-point belt
Other specifications
Chassis curb weight(kg)1560
Load capacity(kg)3000
Max GW(kg)4720
Mini turning diameter(m)10
Mini ground clearance(mm)180
Max climbing ability ()30
Max speed85
Max Braking distance22
Seat2
Mini rate of Fuel consumption(L/100km )8.5
Dump system
Dump angle(°)≥48
Dump time(s)≤20
