Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper
Specifications
Brand Name :
SINOHTC
Model Number :
HTC 10FX
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
20 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
frame :
Articulated frame
drive :
4x2
dump way :
front
starter :
electric
gearbox :
manual
payload :
1 000KG
Description

1Ton 4x2 Hydraulic Mini Dumper,Site Dumper Truck,Self Loader Mini Dumper 1 ton skip truck

Product Description
  1. Wildly used in short-distance transport of bulk material, such as the construction industry, the building site, battlefield, protecting road section, the municipal engineering, underground mines and so on.
  2. 4 *2 Drive, Hydraulic steering, can unload materials smoothly by strong hydraulic pressure unloading system.
  3. Low walking speed, short-distance transport of bulk materials.
  4. Easy operation, small turning radius can be used in a narrow site.
  5. With self lading bucket can realize the multifunction tools.
  6. Deutz Engine as optional makes the performance more reliable
  7. Off road wider tyres as optional can work in muddy and bumpy roads.
  8. Bucket 180°rotating as optional can realize side dumping and dumping in each direction, which can get higher working efficiency.

Site Dumper HTC-10 Technical Specifications
Dumper Model HTC-10
Engine details Model 4DW91-45
Engine Type In-line, water-cooled, 4
cylinders, diesel engine
Rated Power 37kw
Rated Speed 2200r/min
Hydraulic Tipping and steering
Bucket Bucket Capacity 1.2m³
Rated Loading Weight 1000kg
Operating Weight 1500kg
Dimensions Overall Length 3650mm
Overall Height 2550mm
Overall Width 1800mm
Wheel Base 1360mm
Tread 1960mm
Minimum turn radius 4000mm
Tire Front tire:12-16.5 Rear Tire:12-16.5
Drive Type 4*2Wheel Drive

Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper

Hydraulic Mini Site Dumper , Self Loader 1 Ton Loading Skip Loading Dumper

Packaging & Delivery

Packaging Details

Packing for mini dumper:
1.6 units/2decks
2. Standard packing for export, container shipping.
3.Waterproof,dampproof

Delivery Time

10 working days

Mini Site Dumper/Mini Farm Garden Dumper Truck
Our Services
1. Brand new dumper.
2. Solve all problem at the first time.
3. National verified supplier.
4. Fast & Thoughtful service.
5. Engineer can be supplied for oversea service after negociation.
6. 12-Months Guarantee.
