FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
FAW 10 Tons Medium Duty Dump Truck , 2WD RHD Steering Two Axle Dump Truck
Specifications
Brand Name :
FAW
Model Number :
CA3181P2
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Steering :
RHD , Power-assistant
Color :
customer request
Driving :
4x2
Capacity :
10 tons
A/C :
Optional
HS Code :
87042230
Description

FAW 10 tons 2WD RHD dump truck , FAW two axles middle duly dump truck

This FAW 10 tons 2WD RHD dump truck could be extended as clients' request. This truck model special for Africa and South Asia right hand driving clients. It's popular special in Tanzania, Kenya, Pakistan, and many other Africa countries.

Our Product Advantages


(1) Export to more than 30 countries and regions
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.
(3) Competitive Factory Price and Excellent Quality
(4) One year quality guarantee or within 30000km, which comes first.
(5) Regularly callback to know the vehicle's working status.


Specialist supply variou dump trucks, heavy duty dump truck. Our trucks have been widely used for construction site, mine area, sea port bulk transfer, earthmoving transport, garbage transfer station in the world. Competitive price, durable quality, comfortable driving experience,high safty, low consumption. Your best choice.

Technical Parameters

Vehicle Main Dimensions (L x W x H)mm 7200×2500×2960
Wheel base (mm) 4210
Weight in KGS Curb Weight 6550
GVW 16850
Max. driving speed(km/h) 80
Engine Brand FM
Model CA6110-125Z/ CA6DE-18E3/ CA6DE-22E3
Type Diesel Engine,turbo-charging and inter-cooling
Horse Power(HP) 170/ 180/ 220HP
Emission standard Euro II
Gearbox 6TB075M, 6forward&1 reverse. Fast gear 8JS85E, 8 forwards & 1 reverse
Fuel Tank 200L
Clutch Reinforced diaphragm clutch
Tire 9.00R20/ 10.00R20
Brakes Service brake: dual circuit compressed air brake
Parking brake(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Steering Gear power steering, hydraulic steering with power assistance
Box Body
Dimension 4200×2100×750(mm)
Type Self-dumping
Thickness SIDE 4mm 5mm 6mm Bottom 3mm 4mm 6mm 8mm
