4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
4m3 Municipal Construction Mini Dump Truck , Six Wheeler 4 Ton Tipper Truck
Specifications
Brand Name :
FAW
Model Number :
CA3075VH
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
4 UNITS IN ONE 40HQ Container
Used for :
Municipal construction dump truck
Wheelbase :
3260,3560
Tyre model :
7.00R14, 7.50R14
Steering :
LHD,RHD
Color :
White, yellow
HS Code :
8704239000
Description

2 axles Light Duty Dump Trucks , municipal construction dump truck , 6 wheelers dump truck

This 4 tons 6 wheelers 4 m3 dump truck is used for municipal construction. Shipping by 40'HQ. One container 2 trucks. Somewhere sea freight are very expensive by bulk cargo vessel or RO-RO . But 20ft and 40ft container freight are acceptable. Save cost for you is our duty.

Specifications:

Vehicle Description
Type Dump truck Overall Dimensions(mm) 5995*2295*2560
GVW(kg) 6995 Mass in working order(kg) 3350
Design Loading Weight(kg) 4250 Max speed(Km/h) 80
Chassis Description
Chassis Model CA3075 Number of axles 2
Cab TIGER V Allowable Passengers In Cab 3
Wheel base(mm) 3560 F/R track base(mm) 1965/1860
F/R overhang(mm) 1420/1985 Approach/Departure angle(°) 25/20
Spring plate 7/10 F/R axle-load 3200/5795
Tire specification 7.00-14 Tire quantity 6+1
Air conditioner Optional Type of fuel Diesel
Braking system Air braking Electric system 24V
Traction system 4*2 Operation control system Steering Wheel
Engine Description
Engine model CA498E3-12 Engine manufacture FAW DALIAN DEUTZ Diesel Engine Co., LTD
Exhaust(ml) 3186 Horse power 120
Up-parts Description
Cargo body dimensions(mm) 3600*2000*600
Cargo body material Carbon steel Q235
Lifting system Equipped with middle hydraulic system
Optional Configuration
Van thickness,side door,and other china brands hydraulic cylinder,etc.


Product Description:

1) 7.50R20 radial tyre or nylon tyre
2) WheelBase 3850
3) Middle lifting system with single or double hydraulic cylinder
4) Carriage 3800*2000*800
5) Frame 200*70*7mm
6) FAW or CUMMINS engine, 100-140HP,Euro 2/3 emission standard
7) Fuel Tank 130L

Our Product Advantages


(1) One year quality guarantee or within 100000km, which comes first.
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.
(3) Export to more than 30 countries and regions
(4) Competitive Factory Price and Excellent Quality
(5) Customized products available with us
(6) Products Quality Certification SGS CCC ISO

Why do you choose us?

FAQ
Q: What can we do?
A: We can supply you the trailers manufactured with brand parts and competitive price. Also we provide you the proposal for you need.

Q: How can you transport the trailer?
A:We can deliver the trailers via 40FT container (flatbed, drop-side trailers) or RO-RO ship.

Q: How can you ensure your quanlity?
A:Before put into any production, we confirm you the final drawing first and our technicians and QC will stick to the whole process. You are welcomed to check before delivery.

Q: How can you ensure the trailer in good condition when I receive it?
A:Any product will be polished with wax before leave factory yard in case seawater corrosion
during shipping time

Q: Can I have my own logo and painting?
A:Sure, your products will be designed as you need.
