19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃
Specifications
Brand Name :
UTOPTEK
Model Number :
UT224GMP-SFP(1U)
Certification :
CE FCC RoHs
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T, Western Union, Paypal, Wechat, Alipay etc.
Supply Ability :
5000 per month
Delivery Time :
2-3days
Packaging Details :
12pcs/carton without power adapter.
Product name :
L2 Managed industrial switch
Ethernet port :
2xGE SFP+24x10/100/1000M RJ45 POE
Transmission Speed :
10/100/1000Mbps
Material :
Aluminum Alloy
Working Temp. :
-40°C to 85°C
Power input :
AC110~240V
Transmission Distance :
100m
Product size :
442*325*44mm
Warranty :
3years
Installation :
DIN Rail, Wall mount
Lightning protection :
4KV
Description

19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃

UT224GMP-SFP

Product Description:

This UT224GMP-SFP 26-port Industrial Management PoE Switch, provides non-blocking wire-speed performance in harsh industrial environment. It also provides 24-port 10/100/1000BASE-TX RJ45 (PoE) +2G SFP delivered in an IP40 rugged, strong case with redundant power system. It’s suitable for such applications as surveillance system deployments, control management and wireless service in climatically demanding environments with wide temperature range from -40℃ to 65℃.

Features:

• 24-port 10/100/1000Base-Tx RJ-45 with auto negotiation and auto-MDI/ MDI-X function

• Port 1-24 PoE output, PoE budget: 380W max.

• 2G SFP uplink (automatically 100Mbps/1000Mbps SFP module)

• AC110-240V power input

• - 40℃ to 65℃ operating temperature

• IP40 aluminum housing

• Supports 6KV DC Ethernet ESD protection

• Supports 6KV DC EFT protection for power line

• Free Fall, Shock and Vibration Stability

• 19” Rak-mountable hardware design

L2 management

• Support STP/RSTP/MSTP

• Web management, CLI

• IGMP snooping, QOS,VLAN,SNMP

Technical Parameters:

Model No. UT224GMP-SFP
1000Base-TX Port 24G port RJ-45 auto-MDI / MDI-X
PoE Specification PoE Standard: IEEE802.3af/ IEEE802.3at
PoE ports:1-24 port support PoE

Power Output:

Max. 15.4 watts (IEEE 802.3af)

Max. 30 watts (IEEE 802.3at)
PoE budget: Max.380W
Output Voltage: DC48V
Power Pin Assignment:1/2+;3/6-
Power Type: End-span( Mid-span optional)
Uplink Port 2G SFP

Performance Specification

Bandwidth: 256Gbps
Packet Buffer Memory: 12Mbit
Packet Forwarding Rate: 42Mpps

MAC Address Table: 8K
Installation Rak mounted
Maximum Frame Size 10240bytes packet size
Flow Control Back pressure for half duplex, IEEE 802.3x pause frame for full duplex
Enclosure IP40 Aluminum housing

LED Indicator

Power: Red

Fiber: Link 2(Green)

Ethernet: Yellow
Power Input

AC110-240V

Supports built-in over-current 4.0A protection

Supports reverse connection protection
Power Consumption < 400W
Surge protection ± 4KV

Network Protocols

IEEE802.3 10BASE-T;

IEEE802.3i 10Base-T;

IEEE802.3u;100Base-TX/FX;

IEEE802.3ab 1000Base-T;

IEEE802.3z 1000Base-X;

IEEE802.3x;
Network cables

10BASE-T: Cat3,4,5 UTP(≤100 meter)

100BASE-TX: Cat5 or later UTP(≤100meter)

1000BASE-TX: Cat6 or later UTP(≤100 meter)

Industry Standard

FCC CFR47 Part 15,EN55022/CISPR22, Class A

IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air)

IEC61000-4-3 (RS): 10V/m (80~1000MHz)

IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port: ±2kV

IEC61000-4-5 (Surge): Power Port: ±2kV/DM, ±4kV/CM; Data Port: ±2kV

IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz)

IEC61000-4-16 (Common mode conduction): 30V (cont.), 300V (1s)
Certification CE FCC Rohs compliance
MTBF >300,000hours
Dimensions (W x D x H) 442×325×44mm
Weight

Product Weight: 4.5KG

Packing Weight: 5.0KG

Working Environment

Working temperature: -40～65℃ ;

Storage temperature: -40～65℃

Relative Humidity: 5%~95 %( no condensation)
Warranty 1-year replacement with new item; 3-years for main parts.

Packing and Shipping:

UTOPTEK's product are packaged in foam-lined boxes for protection during shipping. The box is then placed inside a larger shipping box with adequate packing materials to prevent damage during shipping and handling. All shipping boxes are labeled with the product name, serial number, and the customer's name and address.

The product is shipped via a reliable courier service such as FedEx, UPS, or DHL. Tracking numbers are provided to customers once the product has been shipped.

19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃

Product photoes:

19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃19'' 1U RACK L2 Managed Industrial 2x1000M SFP+24x10/100/1000M RJ45 POE+1xConsole, POE Network switch -40 ~+85 ℃

Ordering Models:

L2 Managed Industrial Network Switch
UT2G8FM-SFP L2 Managed Industrial 2x1000M SFP port + 8x10/100M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT2G16FM-SFP L2 Managed Industrial 2x1000M SFP port + 16x10/100M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT2G24FM-SFP L2 Managed Industrial 2x1000M SFP port + 24x10/100M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT24GM-SFP L2 Managed Industrial 2x1000M SFP port + 4x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT24GMP-SFP L2 Managed Industrial 2x1000M SFP port + 4x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT28GM-SFP L2 Managed Industrial 2x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT28GMP-SFP L2 Managed Industrial 2x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT216GM-SFP L2 Managed Industrial 2x1000M SFP port + 16x10/100/1000M RJ45 port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT216GMP-SFP L2 Managed Industrial 2x1000M SFP port + 16x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT48GM-SFP L2 Managed Industrial 4x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT48GMP-SFP L2 Managed Industrial 4x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT416GM-SFP L2 Managed Industrial 4x1000M SFP port + 16x10/100/1000M RJ45 port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT416GMP-SFP L2 Managed Industrial 4x1000M SFP port + 16x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT88GM-SFP L2 Managed Industrial 8x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT88GMP-SFP L2 Managed Industrial 8x1000M SFP port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT816GM-SFP L2 Managed Industrial 8x1000M SFP port + 16x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT816GMP-SFP L2 Managed Industrial 8x1000M SFP port + 16x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT224GM-SFP L2 Managed Industrial 2x1000M SFP port + 24x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC10~52V Not include No
UT2816GMP-SFP L2 Managed Industrial 2x1000M SFP port + 8x10/100/1000M RJ45 port+16 Giga POE+1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include 16 POE
UT224GM-SFP 1U RACK L2 Managed Industrial 2x1000M SFP port + 24x10/100/1000M RJ45 port +1xConsole port, -40 ~+85 ℃,power input AC/DC110~240V Not include No
UT224GMP-SFP 1U RACK L2 Managed Industrial 2x1000M SFP port + 24x10/100/1000M RJ45 with POE+1xConsole port, -40 ~+85 ℃, Built-in 450W power,power input AC/DC110~240V Not include 24POE
UT424GM-SFP 1U RACK L2 Managed Industrial 4xCombo SFP/UTP port + 24x10/100/1000M RJ45 port +1xConsole port, -40 ~+85 ℃,power input DC36~72V, AC/DC110~350V Not include No
UT424GMP-SFP 1U RACK L2 Managed Industrial 4xCombo SFP/UTP port + 24x10/100/1000M RJ45 with POE+1xConsole port, -40 ~+85 ℃, Built-in 450W power,power input AC110~350V Not include 24POE
L3 Managed 10G Industrial Network Switch
UT4T8GM-SFP L3 Managed Industrial 4x1G/10G SFP+ port + 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC12~52V Not include No
UT4T8GMP-SFP L3 Managed Industrial 4x1G/10G SFP+ port + 8x10/100/1000M RJ45 POE port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT4T88GM-SFP L3 Managed Industrial 4x1G/10G SFP+ port +8x1G SFP+ 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC12~52V Not include No
UT4T88GMP-SFP L3 Managed Industrial 4x1G/10G SFP+ port+8x1G SFP+8x10/100/1000M RJ45 POE port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include Yes
UT4T16GM-SFP L3 Managed Industrial 4x1G/10G SFP+ port +8x1G SFP+ 8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC12~52V Not include No
UT4T16GMP-SFP L3 Managed Industrial 4x1G/10G SFP+ port+8xPOE+8x10/100/1000M RJ45 port +1xConsole port, DIN Rail type, IP40, 4KV,-40 ~+85 ℃,power input support: DC48~57V Not include 8POE
UT4T24GM-SFP 1U RACK L3 Managed Industrial 4x1G/10G SFP+ port +24x10/100/1000M RJ45 port +1xConsole port, -40 ~+85 ℃,power input support: DC36~72V,AC/DC110-240V Not include No
UT4T24GMP-SFP 1U RACK L3 Managed Industrial 4x1G/10G SFP+ 24x10/100/1000M RJ45 POE port +1xConsole port, -40 ~+85 ℃,power input support:AC/DC110-240V Not include 24POE
UT4T8G24GM-SFP 1U RACK L3 Managed Industrial 4x1G/10G SFP+ port +8x1G SFP
+24x10/100/1000M RJ45 port +1xConsole port, -40 ~+85 ℃,power input support:AC/DC110-240V		 Not include No
UT4T8G16GM-SFP 1U RACK L3 Managed Industrial 4x1G/10G SFP+ port +8xCombo SFP/UTP+16x10/100/1000M RJ45 port +1xConsole port, -40 ~+85 ℃,power input support:AC/DC110-240V Not include No
Industrial desktop Power Adapter
used for
Non-POE		 Input:170～264VAC; Output: DC12V/1A
Input:170～264VAC; Output: DC24V/1A
used for
POE Switch		 Input:170～264VAC; Output: DC52V/1.5A/78W (POE port<=4),
Input:170～264VAC; Output: DC48V/2.5A/120W (POE port<=8),
Input:170～264VAC; Output: DC52V/2.3A/120W (POE port<=8),
Industrial DIN Rail Switching Power Supply
24V 3.125A Input:100V~240VAC 50~60Hz ; Output:DC24V/3.125A/75W
(Suitable for POE port<=4)
48V/1.56A/75W Input:100V~240VAC 50~60Hz ; Output:DC48V/1.56A/75W
(Suitable for POE port<=4)
48V/2.5A/120W Input:100V~240VAC 50~60Hz ; Output:DC48V/2.5A/120W
(Suitable for POE port<=8)
48V/5A/240W Input:100V~240VAC 50~60Hz ; Output:DC48V/5A/240W
(Suitable for POE port<=16)
Industrial SFP Module -40 ~+85 ℃
SFP-FE-SX850-I 155M SFP module,MM dual fiber, 550m, TRX850nm, LC
SFP-FE-SX1310-I 155M SFP module,MM dual fiber, 2km, TRX1310nm, LC
SFP-FE-LX20-I 155M SFP module,SM dual fiber, 20km, TRX1310nm, LC
SFP-FE-BX20-L35-I 155M SFP module,SM single fiber, 20km, TX1310nm/Rx1550nm, LC
SFP-FE-BX20-L53-I 155M SFP module,SM single fiber, 20km, TX1550nm/Rx1310nm, LC
SFP-GE-SX850-I 1.25G SFP module,MM dual fiber, 0.55km, TRX850nm, LC
SFP-GE-SX1310-I 1.25G SFP module,MM dual fiber, 2km, TRX1310nm, LC
SFP-GE-LX20-I 1.25G SFP module,SM dual fiber, 20km, TRX1310nm, LC
SFP-GE-BX20-L35-I 1.25G SFP module,SM single fiber, 20km, TX1310nm/Rx1550nm, LC
SFP-GE-BX20-L53-I 1.25G SFP module,SM single fiber, 20km, TX1550nm/Rx1310nm, LC
SFP-10G-SR-I 10G SFP+ module,MM dual fiber, 300m, TRX850nm, LC
SFP-10G-LR-I 10G SFP+ module,SM dual fiber, 10km, TRX1310nm, LC
SFP-10G-LR-20I 10G SFP+ module,SM dual fiber, 20km, TRX1310nm, LC
SFP-10G-BX20-L27-I 10G SFP+ module,SM Single fiber, 20km, TX1270/Rx1330nm, LC
SFP-10G-BX20-L33-I 10G SFP+ module,SM Single fiber, 20km, TX1330/Rx1270nm, LC

FAQ:

Q1 . What's your MOQ?

A1 .1 pc/pair is ok, we don't have MOQ limited.

Q2.What certification did you get?
A2 : Our products passed the CE,FCC,ROHS and SGS test, you can trust our quality very good.

Q3 :What about your delivery time?
A3:For small sample QTY,we have in stock, need 1day.
For QTY 200-500, usually will take 2-3working days. for big QTY pls contact our sales about details.

Q4.What your common shipping method?
A4:By air, by sea or express(DHL,Fedex,UPS,TNT,EMS...), We will make a perfect delivery plan for you.

Q5.How about your product warranty time?
A5:Our products have 1/3/5years warranty for different product series.

Q6. How to handle quality issues with your product?
We give you the promise if any question during 1 year and not cause by human factors, we will fix it.
