155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik
155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik
155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik
155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik
Specifications
Brand Name :
UTOPTEK
Model Number :
UT-FE-ZX180
Certification :
CE FCC RoHs
Place of Origin :
China
MOQ :
2pcs
Payment Terms :
T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :
2000pcs per week
Delivery Time :
1-2days
Packaging Details :
10pcs to one plastic plate
Transmission speed :
155Mbps
Fiber Type :
Single-mode, Duplex LC
Distance :
180KM
DDM Function :
Support
Power supply :
3.3V
Working Temperature :
0~70℃
Wavelength :
TRX1550nm
Warranty :
3 years
Compatible :
Cisco,Huawei,HP,H3C,Juniper,Extreme etc..
Description

155Mbps 180km SFP Transceiver

Hot Pluggable, Duplex LC, +3.3V, 1550nm, DFB-LD, Single-mode, DDM

Description:

UTOPTEK’s UT-FE-ZX180 Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1550nm DFB laser, up to 29dB link budge ensure this module SONET OC-3/SDH STM-1 180Km application.

Features:

Brand UTOPTEK, OEM
Condition 100% New
Form Factor SFP
Wavelength: TRx1550nm
Distance 180KM
Data Rate (max) 155Mbps
Working Temperature (°C) 0°C~70°C
Storage Temperature (°C) -40°C~+85°C
Relative Humidity 0~85%
Voltage Supply 3.3--5v
Connector LC
Warranty 3 years
Compatible with Cisco, Haiwei, HP etc.
Time of delivery 1-2 working days
Package 10 pcs/box

Applications:

  • 100Base-ZX Ethernet
  • Metro/Access Networks
  • 2×Fiber Channel
  • Other Optical Links

Prpducts Picture:

155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik

155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik

Factory Show:

155M SFP SMF Duplex LC 180km 1550nm DDM SFP optical Transceiver Compatible Cisco/Huawei/HPE/Mikrotik

Ordering Information:

Part No. Data Rate Form Factor Distance Wavelength Transmitter Receiver Interface Temp.
UT-FE-SX850 155Mbps SFP 2km 850nm VCSEL PIN LC 0-70℃
UT-FE-SX1310 155Mbps SFP 2km 1310nm FP PIN LC 0-70℃
UT-FE-LX20 155Mbps SFP 20km 1310nm FP PIN LC 0-70℃
UT-FE-EX40 155Mbps SFP 40km 1310nm DFB PIN LC 0-70℃
UT-FE-ZX60 155Mbps SFP 60km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX80 155Mbps SFP 80km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX100 155Mbps SFP 100km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX120 155Mbps SFP 120km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX160 155Mbps SFP 160km 1550nm DFB PIN LC 0-70℃
UT-FE-BX20-L35 155Mbps BiDi SFP 20km Tx1310nm/Rx1550nm FP PIN LC 0-70℃
UT-FE-BX20-L53 155Mbps BiDi SFP 20km Tx1550nm/Rx1310nm FP PIN LC 0-70℃
UT-FE-BX40-L35 155Mbps BiDi SFP 40km Tx1310nm/Rx1550nm FP PIN LC 0-70℃
UT-FE-BX40-L53 155Mbps BiDi SFP 40km Tx1550nm/Rx1310nm FP PIN LC 0-70℃
UT-FE-BX60-L35 155Mbps BiDi SFP 60km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX60-L53 155Mbps BiDi SFP 60km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX80-L35 155Mbps BiDi SFP 80km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX80-L53 155Mbps BiDi SFP 80km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX100-L35 155Mbps BiDi SFP 100km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX100-L53 155Mbps BiDi SFP 100km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX120-L35 155Mbps BiDi SFP 120km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX120-L53 155Mbps BiDi SFP 120km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
