STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper
Specifications
Brand Name :
UTOPTEK
Model Number :
UT-FE-LX20
Certification :
CE FCC RoHs
Place of Origin :
China
MOQ :
2pcs
Payment Terms :
T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :
2000pcs per week
Delivery Time :
1-2days
Packaging Details :
10pcs to one tray
Transmission speed :
155Mbps
Fiber Type :
Single-mode, Duplex LC
Distance :
20KM
DDM Function :
Support
Power supply :
3.3V
Wavelength :
TRX1310nm
Warranty :
12 months
Material :
Iron
Power :
3.3V
HS code :
8517795000
Package :
10pcs per tray
OEM :
support
Working Temperature :
0~70℃
Compatible :
Cisco,Huawei,HP,H3C,Juniper,Extreme etc..
Description

155Mbps 20km SFP Transceiver

Hot Pluggable, Duplex LC, +3.3V, 1310nm, FP-LD, Single-mode, DDM

Description:

UTOPTEK’s UT-FE-LX20 Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 15dB link budge ensure this module 1000Base Ethernet 20km application.

Features:

Brand UTOPTEK, OEM
Condition 100% New
Form Factor SFP
Wavelength: TRx1310nm
Distance 20KM
Data Rate (max) 155Mbps
Working Temperature (°C) 0°C~70°C
Storage Temperature (°C) -40°C~+85°C
Relative Humidity 0~85%
Voltage Supply 3.3--5v
Connector LC
Warranty 12 months
Compatible with Cisco, Haiwei, HP etc.
Time of delivery 1-2 working days
Package 10 pcs/tray

Applications:

  • 100Base-LX Ethernet
  • Metro/Access Networks
  • 2×Fiber Channel
  • Other Optical Links

Prpducts Picture:

STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniperSTM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniperSTM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper

STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper

Factory Show:

STM1 sfp module 155M spf singlemode LC 20km 1310nm sfp transceiver compatible cisco,huawei,hp,aruba,mikrotik,juniper

Ordering Information:

Part No. Data Rate Form Factor Distance Wavelength Transmitter Receiver Interface Temp.
UT-FE-SX850 155Mbps SFP 2km 850nm VCSEL PIN LC 0-70℃
UT-FE-SX1310 155Mbps SFP 2km 1310nm FP PIN LC 0-70℃
UT-FE-LX20 155Mbps SFP 20km 1310nm FP PIN LC 0-70℃
UT-FE-EX40 155Mbps SFP 40km 1310nm DFB PIN LC 0-70℃
UT-FE-ZX60 155Mbps SFP 60km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX80 155Mbps SFP 80km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX100 155Mbps SFP 100km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX120 155Mbps SFP 120km 1550nm DFB PIN LC 0-70℃
UT-FE-ZX160 155Mbps SFP 160km 1550nm DFB PIN LC 0-70℃
UT-FE-BX20-L35 155Mbps BiDi SFP 20km Tx1310nm/Rx1550nm FP PIN LC 0-70℃
UT-FE-BX20-L53 155Mbps BiDi SFP 20km Tx1550nm/Rx1310nm FP PIN LC 0-70℃
UT-FE-BX40-L35 155Mbps BiDi SFP 40km Tx1310nm/Rx1550nm FP PIN LC 0-70℃
UT-FE-BX40-L53 155Mbps BiDi SFP 40km Tx1550nm/Rx1310nm FP PIN LC 0-70℃
UT-FE-BX60-L35 155Mbps BiDi SFP 60km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX60-L53 155Mbps BiDi SFP 60km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX80-L35 155Mbps BiDi SFP 80km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX80-L53 155Mbps BiDi SFP 80km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX100-L35 155Mbps BiDi SFP 100km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX100-L53 155Mbps BiDi SFP 100km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
UT-FE-BX120-L35 155Mbps BiDi SFP 120km Tx1310nm/Rx1550nm DFB PIN LC 0-70℃
UT-FE-BX120-L53 155Mbps BiDi SFP 120km Tx1550nm/Rx1310nm DFB PIN LC 0-70℃
