High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin
Specifications
Brand Name :
TAIMI
Model Number :
TM-12095 3V 5V 9V 12V magnetic buzzer
Certification :
ISO9001、ISO14001、IATF16949
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1000000/month
Delivery Time :
10~15days
Packaging Details :
safe packaging
Rated voltage (vp-p) :
DC3V 5V 9V 12V
Function :
Alarm sound buzzer
Min Sound Output :
90dB 5VDC/30cm
Type :
Electromagnetic buzzer
Main body diameter :
30mm
Height :
9.5mm
Current consumption (maximum) :
max.30mA
Output sound pressure (minimum) :
min.90dB
Operating temperature :
-20°C to +60°C
Storage temperature :
-30 ° C to +70 ° C
Material :
ABS
Color :
Black
Description

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

High sound 5v horn alarm siren buzzer Electronic Alarm Buzzer

Electronic Alarm buzzer

Specifications
Rated Voltage(Square Wave) 12V
Operating Voltage 3-20V
Rated Current(Max) 15mA
Min Sound Output at 10cm 95dB
Resonant Frequency 3400±500Hz
Tone Nature Single
Operating Temperature -30~+70℃
Storage Temperature -40~+85℃
Weight 4g
Housing Material MPPO (Black)
Lead Pin Material Red Copper(DSn)

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

Classification of buzzer :
1. According to the principle of its driving mode, it can be divided into: active buzzer (including driving circuit, also called self-excited buzzer) and passive buzzer (external drive, also called other excited buzzer) Sounder);
2. According to the different construction methods, it can be divided into: electromagnetic buzzer and piezoelectric buzzer;
3. According to the different packages, it can be divided into: DIP BUZZER (Pin Buzzer) and SMD BUZZER (SMD Buzzer);
4. According to the difference of current, it can be divided into: DC buzzer and AC buzzer. Among them, DC is the most common piezoelectric buzzer, which uses piezoelectric material, that is, when the external force causes the piezoelectric material to occur Piezoelectric materials generate electrical charges during deformation. Similarly, piezoelectric materials deform when energized.
The electromagnetic buzzer mainly uses the characteristics of the conductive conductor to generate a magnetic field, and uses a fixed permanent magnet and the conductive conductor to generate magnetic force to push the tympanic membrane fixed on the coil.
Due to the different sounding principles of the two buzzers, the piezoelectric structure is simple and durable but has a single tone and color difference. It is suitable for devices such as alarms. The electromagnetic type is mostly used for voice, music and other equipment because of its good timbre.

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

Electromagnetic buzzer Workshop

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

Electronic Alarm Buzzer Certifications

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

Transport for BUZZER

High Sound 5v Siren Horn Electronic Alarm Buzzer Red Copper Lead Pin

8. Piezo Siren FAQ

1. Q: When can we get the reply?
Any inquiries will be replied within 24 hours.
2. Q: Can i have samples?
A: Yes. Sample is surely ok. We can even send you free sample and you should only pay for the freight fee.
3. Q: What about minimum order quantity?
A: We have no limit for MOQ, so you can even buy only 1 piece. Welcome to buy sample to test first.
4. Q: What about delivery time?
A: We will send sample to you within 3 days.
Production for big quantity needs 20 to 25 days. And it also depends on product and quantity.
5. Q: What about terms of payment?
A: Payment terms: T/T, west Union, Paypal and L/C etc.
6. Q: How you will send the goods to us?
A: We will send the goods to you by Air (DHL, Fedex, UPS, TNT) and Sea shipping etc.
7. Q: Are you trading company or manufacturer ?
A: We are in China buzzer manufactory
8. Q: Do you support OEM and ODM services?
A: Yes, surely support. we can customize products according to the drawing.
9. Q: Can you provide driven circuit?
A: Yes, of course sure.
10. Q: Can you solve technical problems for us?
A: Yes, Our Technical team will try our best to support you.
