PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
Specifications
Brand Name :
TaiMI
Model Number :
TM-10-160kHz
Certification :
ROHS/REACH
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, PAYPAL
Supply Ability :
10000000pcs/Month
Delivery Time :
10~15 work day
Packaging Details :
safety packing
MATERIAL :
PZT/SUS
SIZE :
10mm/13.8mm/16mm/20mm
Frequency :
113k/160k/180k
voltage :
5V
parking :
safety parking
power :
2W
Description

PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical Use

Medical use Piezoceramic atomizer Transducer Nebulizer for hospital Air Compressed

1. Material: Metal and Ceramic

2. Size: DIA 13.8mm, 6.5mm Height

3. Fogger ceramic disc Low noise operation, low consumption

4. Used for Industrial humidifying, Garden fog

5. Fogger ceremic long operation life, high stability and reliability

Applications:

Piezo transducer vibration atomizer transducer matter dispersion


sonar transducer Ultrasonic Sensor wall thickness sensor


material stress sensor pressure sensor, biomedical probe


piezo electricity harvesting fish finder transducer compression sensor


piezo expansion sensor beauty transducer Ultrasonic mixing


ultrasonic medical Ultrasonic cleaning More other application

for Ultrasonic Welding,

for Tooth-brushing,

Piezoceramic Vibrator

for beauty devices

Piezoceramic Vibrator for beauty devices

Technical parameters

1.Fr=160KHz±5KHz

2.Ro=max.150Ω

3. Cp=3100±15%

4.Kp=min. 55%

5.Qm=min. 800

6.tanδ=max. 0.5%

7.working time≥1000h

8.operating voltage:DC3~12V

9.operating temperature:+5°c~+40°c

10.power:2.5w

Commonly used specifications
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
PZT SUS Ultrasonic Humidifier Transducer Nebulizer For Medical use
