Specifications
Brand Name :
Osmanuv
Model Number :
OSM-ZY- (300~1320)T
Place of Origin :
China
MOQ :
1 set
Delivery Time :
30 WORK DAYS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Packaging Details :
Wooden box
Certification :
ISO9001
Product Name :
Thermal transfer equipment
Size :
3000 mm x 2300 mm x 2100mm
Color :
Computer white / Green
Speed :
1-3 m/min
Supply voltage :
380V 50HZ
Working height :
850mm (belt height from ground), roller height with position display
Description

3m/Min 850mm Height Press Rotary Heat Transfer Machine Roll To Roll

Description:

suitable for all kinds of wood, plastics, ceramics, calcium silicate board, metal and other plane overlay a layer of heat transfer film, so that the plate surface pattern level more clear, more three-dimensional sense.

Describe

1 Mechanical dimension:

3000mm long * 2300mm wide * 2100mm high.

(Subject to the actual size).
2 Effective working size

a. Effective width: 1300mm;

b: Thickness: 1-60mm

c, Length (shortest) : 600mm.
3 Supply voltage: 380V 50HZ.
4 Material The shell is made of 1.5mm cold-rolled plate bending and welding, the surface is treated with liquid paint, the frame is made of 100*50mm channel steel, and the supporting wall is made of 20cm steel plate (A3 material).
5 Fitting part:

the double roll extrusion at the same time, so that the transfer film evenly bonded to the substrate, and through automatic entanglement device to prevent the film wrinkle.
6 Silica gel press roller: diameter: ￠210mm, length: 1400mm, high quality high temperature resistant silica gel made of Japan, wear-resisting, good elasticity, hardness can be customized according to customer requirements (30 degrees -- 50 degrees) between, can be resistant to all kinds of solvent with high quality coupling transmission, bearing using Japanese NSK bearing, Taiwan Bay Delphi frequency converter control cots speed.
7 Conveying mode Adopt cots to transfer, smooth conveying and long service life.
8 Transportation speed: 1 ~ 3 meters/min.
9 Working height: 850mm (belt height from ground), roller height equipped with position display.
10 Electrical appliances: OMRON relay, Siemens motor, Delta frequency converter, reducer, CHNT contactor, delay using CKC brand, switch using Japan Wazumi company production, all in line with CE standard.
11 Safety device:
The machine has leakage circuit breaker, motor overload protection, abnormal emergency switch, control line fuse and other compliance with international safety standards.

3m/Min 850mm Height Press Rotary Heat Transfer Machine Roll To Roll

FAQ

Q: Are you trading company or manufacturer?
A: We are a manufacturer owns foreign trade independent import and export rights. Our factory is located in Guangdong, China.

Q: How can I know your machine has good quality?
A: Firstly, we will have your samples for a trial on our machines, and make a video for you to watch the testing, factory visit is also available. Moreover, our products are widely used in China, Southeast Asia, South America, and Europe.

Q: What certifications do you have?
A: Fully in accordance with the GMP & ISO standard production and our products have passed CE certification for exporting.

Q: What is your Quality Warranty?
A: One year warranty; Lifelong Maintenance and Technical Support.
