Sustainable Manufacturing Eco-Conscious Design 14 Stage Microwave Drying Machine For Pulp Sea Food

Product Description:
The Standard Microwave Drying Production Line is designed for efficient and uniform drying of various materials, particularly suitable for industries requiring quick and consistent moisture removal. This model is ideal for medium-scale production environments.

Technical Parameters:

• Input Power: 380V±10%, 50Hz±2%

• Microwave Output Power: ≥130KW

• Microwave Frequency: 2450MHz±50Hz

• Conveyor Belt Speed: 0.3-5 meters/min

• Dimensions: 23380mm (L) × 1680mm (W) × 1100mm (H)

• Number of Chambers: 14

• Cooling System: Water-cooled magnetron and oil-immersed water-cooled transformer

Application:

• Drying of water-based paints, coatings, and other moisture-sensitive materials.

• Suitable for food processing, pharmaceutical, and chemical industries.

Customization:

• Adjustable conveyor belt height (850mm ±50mm).

• Customizable microwave power settings (30%-100%).

• Optional additional safety features and monitoring systems.

Features:

• Uniform Heating: Ensures consistent drying without hot spots.

• Energy Efficient: Reduces energy consumption compared to traditional drying methods.

• Safety Compliance: Meets GB 10436-1989 and GB 16798-1997 standards.

Support and Services:

• Installation: On-site installation and commissioning.

• Training: Comprehensive operator training.

• Maintenance: Regular maintenance and support packages available.

Packing and Shipping:

• Packing: Standard export packaging with wooden crates.

• Shipping: Worldwide shipping with door-to-door delivery options.

FAQ:

1. What is the lifespan of the magnetron?

   • The magnetron has a lifespan of 6000-8000 hours of continuous operation.

2. Can the conveyor belt speed be adjusted?

   • Yes, the conveyor belt speed is adjustable from 0.3 to 5 meters per minute.

3. Is the equipment suitable for food processing?

   • Yes, it complies with food safety standards and is suitable for food processing.

4. What is the power consumption of the equipment?

   • The total input power is approximately 130KW.

5. Does the equipment come with a warranty?

   • Yes, a standard one-year warranty is provided, with extended warranties available.
