220V Screen Printing LED Ink 365nm UV Conveyor System
220V Screen Printing LED Ink 365nm UV Conveyor System
220V Screen Printing LED Ink 365nm UV Conveyor System
220V Screen Printing LED Ink 365nm UV Conveyor System
Specifications
Brand Name :
BirdUV
Place of Origin :
China
MOQ :
>=1 Sets
Price :
negotiable
Supply Ability :
100 Set/Sets per Month
Packaging Details :
Carton
Certification :
CE
Support Dimmer :
Yes
Voltage :
220V
Product name :
UV LED Conveyor system
Application :
Adhesive
Wavelength :
365nm 385nm 395nm 405nm
Cooling Method :
Nature cooling/Fan cooling
Input Voltage :
AC220V
Service time :
20000HRS
Warranty :
1 Year
Port :
Shezhen, Guangzhou
Description

Customized size uv curing dryer conveyor belt system Tunnel screen printing UV Curing conveyor for LED ink

Product Introduction

The system mainly consists of a control system, a UVLED head and a conveyor belt. The machine UVLED irradiation head with imported high-intensity UV LED integrated UV wavelength of 365nm, single LED front quartz mirror installed to improve the LED light output accuracy and uniformity, uniformity up to 90%, the whole machine material 304 stainless steel, Teflon conveyor belt, width of conveyor is 300mm.

Specification Parameter

1. Control system:

* panel display,touch operation, real-time

* monitoring of head of the working state

* intensity adjustable from 0-100%

* temperature monitoring

* infrared sensor control, conveyor would stop when the UV LED system lighting

* speed of conveyor:0-10m/min adjustable

* whole machine size:L1500*W581*H1640mm

2. UV LED irradiation head

* wavelength:365nm

* curing area:200x300mm

* optic power:800mw/cm2(10mm irradiation distance)

* recommended height of irradiation:5-100mm

* dimension:L334*W224*H61mm

* cooling method: air cooling

Product feature:

1. Instant ON/ OFF, NO pre-heating required.

2. Adjustable curing distance, UV output intensity and conveyor speed

3. Energy saving and environmental protection

4. infrared sensor to stop, protect your products

5. No infrared radiation, cold light source, suitable for all types of heat-sensitive material curing.

6. Conveyor belt with adjustable speed

Main Application:

PCB/PCBA Conformal Coating curing(UV glue, UV varnish, UV oil)

TP UV glue curing

Medical instrument uv glue curing (one time using medical parts)

UV Printing (offset printing, screen printing, silk printing, lable printing)

Control system features:

1: Touch screen display and operation, real-time monitoring of the head of the working state

2: Intensity adjustable from 0-100%

3: Temperature monitoring

4: Infrared sensor control, work mode selection

5: English operation interface.

Product Advantages:

1. Extra-long life: 10000h~30000h

2. Energy saving: save 80% electrical energy than Mercury lamp

3. UV output adjustment: From 1% to 100%

4. Multiple control modes : Constant current, pedal control, intelligent optical and manual modes

5: Photoelectric induction, instant on/off, no preheating required.

6: No mercury, No Ozone, eco-friendly

7: Cold light source, low temperature

8: Stable output, high uniformity.

220V Screen Printing LED Ink 365nm UV Conveyor System

220V Screen Printing LED Ink 365nm UV Conveyor System
