Three Roller Surface Rewinding Machine for Double-Sided Tape/ Masking Tape
Three Roller Surface Rewinding Machine for Double-Sided Tape/ Masking Tape
Three Roller Surface Rewinding Machine for Double-Sided Tape/ Masking Tape
Three Roller Surface Rewinding Machine for Double-Sided Tape/ Masking Tape
Specifications
Brand Name :
United Win
Model Number :
UW-J1310/J1610
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD
Supply Ability :
5 sets/ month
Delivery Time :
3 months
Packaging Details :
Wooden case
Name :
Three Roller Surface Rewinding Machine
Material :
BOPP Tape Jumbo Rolls
Voltage :
220V,380V
Effective Width :
1300mm/1600mm
Power :
120KW(MAX)
Dimension(LxWxH) :
1950*2830*1315mm
Control :
PLC control with touch screen
Automatic Grade :
Automatic
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
1 Year
Description

Three Roller Surface Rewinding Machine UW-J1310/J1610 Adhesive Tape Machine

Feartures:

1. Three roller surface driving solve effectively the problem of material stretching and wrinkle.

2. Speed of pressure roller and driving roller can be adjusted to suit different materials.

3. Auto-labelling system is optional to suit different material and requirement of customers.

4. Equipped with sound insulating cover, effectively reduce noise to fit environment requirement.

5. The whole machine has high automatic and efficiency,easy operation.

Specifications:

Model UW-CJ1310 UW-J1610
Effective width(mm) 1300 1600
Max.Rewinding dia(mm) 800 800
Unwinding tension control 200 200
Mechanical speed(m/min) 200kg magentic powder 200kg magentic powder
Total power 120(MAX) 120(MAX)
Dimension(LxWxH)(mm) 1950*2830*1315 1950*3130*1315

Application:

Suitable for cutting of double sided tape/ kraft paper/ masking tape/foam tape/PET/PVC/PE/ cloth base material etc

Package and Dlivery:

Three Roller Surface Rewinding Machine for Double-Sided Tape/ Masking TapeThree Roller Surface Rewinding Machine for Double-Sided Tape/ Masking Tape

FAQ:

1. Are you a factory?
Yes, our company was established in 1998. It is the only comprehensive manufacturing enterprise in China produce both tape and
tape machine.


2. Can I get some tape samples for testing before placing order?
Yes,we can provide you some free samples for your reference.


3. How long is the delivery time for your tape?
The first order is 15 days after deposit,then other orders are about 7-10 days after deposit.

4. How could I get the quotation?
Tape: Please let me know the specification(thickness,width,length),quantity,application and other requirements according to your
needs so that we can provide an accurate quotation.
Machine: please provide the type of machine required and other special requirements.

5. What is quality guarantee policy?
12 months guarantee for all goods from our company, but we do not accept any broken by man.

6. When we receive the box, find any items missing or defective, how should we do?
Please contact us ASAP, we will check and give you best solution soon.

7. Do you control the items quality?

Each machine strictly tested one by one before shipping.

8. How long is the delivery time for your machine?
After deposit is about 30 days.
