Movable Vacuum Transformer Oil Purifier 12000LPH Double Stage 50mm
Movable Vacuum Transformer Oil Purifier 12000LPH Double Stage 50mm
Specifications
Brand Name :
SINO-NSH
Model Number :
VFD-200
Certification :
CE, ISO,SGS, SASO, SONCAP
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
15 working days
Packaging Details :
Wooden Case
Name :
Movable Double Stage Vacuum Transformer
Product Capacity :
12000LPH
Color :
Customizable
Power Supply :
Fully Customizable
Material :
Stainless Steel/Carbon Steel
Weight :
1700kg
Inlet Diameter :
50mm
Outlet Diameter :
50mm
Description

Movable Double Stage Vacuum Transformer Oil Purifier 12000LPH

The technologies utilized by NSH-VFD-200

SH-VFD-200 utilizes coacervation technology, coalescing technology, separating technology, and refined purification technology.

What is the problem of oil products that NSH-VFD-200 is committed to solving?

Removing free, soluble water, carbon, free and dissolved gases, and particulate matter from the insulating oil effectively and rapidly.

Advantages of the NSH-VFD-200

Enhance the value of breakdown voltage greatly.
Easy handling and maintenance.
Online work
Lower maintenance and replacement expenses
High efficiency and effectiveness
Small size, lightweight, low noise
Various sizes and configurations (shields) are available.

Corollary Equipment-VR Vacuum Pump Set:


SINO-NSH-VR is a unit that creates a vacuum in transformers and other equipment with a double-stage vacuum system.

Parameter Value
VR-30 VR-70 VR-150 VR-300 VR-600 VR-900
Capacity, liters/hour 100 250 500 1000 2000 3000
Total Power, kW 3 3 5 7 8 13
Power supply Fully Customizable
Maximum Vacuum Range, Pa 0.06
Outlet Diameter, mm 32 32 40 40 50 65
Dimensions length, mm 900 550 1000 1200 1500 1950
width, mm 800 900 800 800 1000 1800
height, mm 1200 800 1200 1200 1200 1300
Weight(without trailer), kg 450 550 600 900 950 1950

70W 18000L/H Vacuum Insulation Oil Purifier Description

Vacuum Lubricating Oil Purifier Technical Parameters:

Parameter Value
LV-10 LV-20 LV-30 LV-50 LV-100 LV-150 LV-200
Capacity, liters/hour 600 1200 1800 3000 6000 9000 12000
Heating Power, kW 15 18 30 45 90 120 180
Total Power, kW 17 21 35 50 96 126 186
Power supply Fully Customizable
Inlet Diameter, mm 20 20 20 25 40 50 65
Outlet Diameter, mm 20 20 20 25 40 50 65
Dimensions
(without trailer)		 length, mm 1350 1500 1550 1900 2200 2400 2900
width, mm 1100 1200 1250 1400 1500 1600 1800
height, mm 1700 1750 1800 1800 1850 1900 2000
Weight(without trailer), kg 600 800 900 1150 1500 1700 2400
Processed Oil Spec Water Content, ppm ≤100
Dielectric Strength, Kv ≤6
Filtration Fineness, um ≤5( or 1-5 as needed )

Movable Vacuum Transformer Oil Purifier 12000LPH Double Stage 50mm

Other Models Oil Purifier:

TF Series:
TF series oil filter is a filtration and dehydration unit with thermal and vacuum processing, it's ideal for filtration and dehydration of turbine oil, this unit can extend turbine oil life by removing contaminates from oil, such as water, gas, and particulates, improve the oil properties.
FV Series:
LV series oil filter is a stainless steel machine with thermal and vacuum processing, it's mainly used to improve the properties of phosphate ester fire-resistant oil in generator sets.
GER Series:
Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, and other used lubrication oil for machinery.
GED series:
it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality.

Notice:

1. Switch on the power supply, the ground cable must be connected before operation.

2. Before the operation, pay attention to the direction of motor rotation, which should conform to the arrow direction.

3. When there is no oil circulation, do not open the heater, otherwise, it will burn out the heater, or it will explode.

PS: we accept customization, welcome to inquiry!!
