Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier
Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier
Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier
Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier
Specifications
Brand Name :
SINO-NSH
Model Number :
VFD-200
Certification :
CE, ISO,SGS, SASO, SONCAP
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
15 working days
Packaging Details :
Wooden Case
Product Power :
132kW
Product Capacity :
12000L/h
Color :
Custom
Power Supply :
Fully Customizable
Material :
Stainless Steel/Carbon Steel
Warranty :
1years
After Warranty Service: :
Video Technical Support, Online Support
Product Name :
Double-Stage Vacuum Transformer Oil Purifier
Description

Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier

Vacuum Transformer Oil Purifier Characteristics:


1. Vacuum oil filter is also called vacuum efficient oil filter, oil filter, vacuum clean oil machine.
2. Using vacuum oil inlet, a tubular rotary injector is installed to reduce the resistance, speed up the rotation, and increase the oil and gas separation effect.
3. Small size, light weight, easy to move, low noise, long continuous working time, stable performance, easy to operate.

Function:


It can to increase special indexes of insulation oil through remove dissolved and free water, dissolved gas and particulate impurities effectively.Oil purification is a vital undertaking that helps in the maintenance of machines.

Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier

Vacuum Transformer Oil Purifier Technical Parameters:

Parameters Value
VFD-30 VFD-50 VFD-75 VFD-100 VFD-150 VFD-200 VFD-300
Capacity, liters/hour 1800 3000 4000 6000 9000 12000 18000
Heating Power, kW 24 30 48 60 90 120 150
Total Power, kW 29 36 56 69 100 132 170
Power supply Fully Customizable
Inlet Diameter, mm 25 32 32 40 40 50 65
Outlet Diameter, mm 25 32 32 40 40 50 65
Dimensions
(without trailer)		 length, mm 1350 1500 1550 1900 2200 2400 2900
width, mm 1100 1200 1250 1400 1500 1600 1800
height, mm 1700 1750 1800 1800 1850 1900 2000
Weight(without trailer), kg 600 800 900 1150 1500 1700 2400
Processed Oil Spec Water Content, ppm ≤5
Dielectric Strength, Kv ≥75
Filtration Fineness, um ≤5( or 1-5 as needed )
Gas Content, % ≤0.1

Other Optional for Transformer Oil/Insulation Oil:


VF series-- Single-Stage Vacuum Transformer oil Filtration machine.
VFD-R series-- Double-Stage Vacuum Black Insulation Oil Regeneration Machine

Filter maintenance:


1. Check the blocking of the filter element
2. In the case of no blocking 1 to 3 months to replace or clean the filter element, at the same time empty the shell visceral oil, clean the interior
3. Regular replacement of the filter
4. Can not bring foreign bodies

Other Models Oil Purifier:

TF Series:
TF series oil filter is a filtration and dehydration unit with thermal and vacuum processing,it's ideal for filtration and dehydration of turbine oil, this unit can extend turbine oil life by removing contaminates from oil, such as water, gas and particulates, improve the oil properties.
LV Series:
LV series oil filter is a dehydration and degassing unit with thermal and vacuum processing, it's a multifunctional purifier which can treat various kinds of lubricant oils.
FV Series:
LV series oil filter is a stainless steel machine with thermal and vacuum processing, it's mainly used to improve the properties of phosphate ester fire-resistent oil in generator set.
GER Series:
Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used lubrication oil of machinery.
GED series:
it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality.

Package & Delivery:

Reliable Enclosed Dehydration Degassing 12000L/H Vacuum Transformer Oil Purifier
