Industrial Vacuum Banana Chips Maker Machine No Color Fading High Efficiency

• working principle:
  Fruit and vegetable chips are made of fresh fruits and vegetables as the main raw materials, edible vegetable oil as the heat medium, and adopt advanced technologies such as low-temperature vacuum frying (VF), which can quickly dehydrate and dry in a very short period of time, and obtain very low water content. Fruit and vegetable foods have low oil content and are crisp and not greasy. They preserve the original shape, color, fragrance and taste of fruits and vegetables, and are rich in vitamins, minerals, fiber and other nutrients. Low fever and other characteristics.

• Liuyi's Banana chips Vacuum Frying Machine Advantage

1. The heating speed is fast, only need 8-13mins to reach required temperature. The oil cycle area is 35-40m³.

2. Fully automatic computer control from feeding to de-oiling. 1 person can operate 5 sets.

3. Equipped most advanced vacuum pump, including our own design. The vacuum degree can be maintain -0.098mpa all the time. The noise can be controlled below 60db.

4. The de-oiling speed is 300r/min. It also can be changed according to different products.

5. Reasonable oil inlet design keep the even oil washing. The product has good color.

• Fruit Chips Vacuum Frying Machine Processing Step

We already do many test for banana chips for our customer. Below is the pre-treatment process:

Raw material select - clean - peel - slice – sterilization/pretreatment - vacuum frying – de-oiling - seasoning - packaging

• Models & Details

• Liuyi's Vacuum Frying Machine Core Components

- Oil storage tank

It is for oil storage before frying. The oil will be heated in it firstly. During frying, the oil will be cycled between oil storage tank and frying pot.

- PLC control system

Brand: Mitsubishi

It is control the whole machine.

This make the machine operate fully automatically. No need to manual during processing.

- Touch screen

Brand: Mitsubishi

The new type is connect directly with the machine body, not separate part.

It is easy to understand and operate.

- Electrical Components

Brand: Schneider

It mainly includes dis-connector, frequency converter and thermal overload relay

Catalog for Automatic Vacuum Frying Machine.pdf
