50-10000L stainless steel mixing tank for food and chemical with PLC control

Product Description:

1. The mixing system adopts advanced frequency controller for adjusting stir speed, which is suitable for the production of different materials.

2. According to the process requirements, the machine could do heating or cooling for materials, heating method can be used according to customer requirements, steam or electric heating are both available.

3. There are many kinds of mixing paddle, like frame stirrer, scraper stirrer, arm stirrer, etc. Customer could choose different mixing paddle according to the production needs.

4. Use high quality SUS304 or SUS316L stainless steel, and the tank and pipeline are all mirror polished.

5. Can be equipped with vacuum pump for defoaming (optional).

6. High speed disperser could mix and disperse different viscosity material powerfully and completely, which could save energy consumption and shorten production period.

7. Stainless steel cabinet full monitoring equipment operation, and can display the data of temperature, stirring speed etc.

8. The material could be directly discharged from bottom outlet, or machine could be equipped with rotor pump for material discharge.

Stainless steel mixing tank features:

1. Optional PLC touch screen

2. Frequency converter for speed adjustment.

3. Inside surface is Ra ≤0.4μm

4. Outside surface is mirror or matt polish.

5. Electric and steam jacket heating available for user to choose

6. Mixing pot in contact of material made of SS316L and SS304 without dead corner

7. Available with high shear homogenization mixer resulting in high shear and high dispersion force with excellent emulsifying results

Stainless steel mixing tank specifications:

1. Volume: 50-15000L

2. Material: SS316L & SS304

3. Insulation material: rock wool

4. Structure: Jacketed vessel, vessel with jacket and insulation

5. Application: liquid mixing for pharmaceutical, cosmetic and dairy products

6. Components: mixing device, vent filter, temperature gauge, level gauge, manhole, sight glass with lamp and cleaning ball or according to client’s detailed requirement.

Mixing tank as a equipment are suitable for the pharmaceutical & cosmetic industries for
1. Pharmacy industry: Syrup, Suspension, Injection Solution, Eyedrop, oral solution, injection solution,Carbomer of gel.

2. Health product industry: soft gel preparation, etc

3. Cosmetic industry:cream, ointment, lotion,toothpaste, hair color

Capcity: 10L-10000L

Pressure: Atmospheric pressure or pressure vessel (0.1mpa-0.6mpa)

Material: Stainless steel 316L, 304 or special reqirements

Mixing type for choose:paddle mixer, propeller mixer, PTFE scraper mixer, Top homogenizer, bottom homogenizer, bottom magnetic mixer, high shear mixer

Heating Choose:Steam or electrical heating or hot-water circulation.

Structure: signle layer or with insulating layer or with jacket and insulating layer.

Thermal insulation material for choose: PU or rock wool etc.

Jacket type for choose: full jacket, dimple jacket, coil jacket, half pipe.

List of nozzles(for choose): Manhole, CIP and SIP port, pressure gauge, temperature sensor, material inlet, material outlet, respirator(vent filter), sight glass, lamp, handhole, vacuum port, reserve port etc.

CIP: cleaning ball.

SIP: As a option.

Loading cell: use Mettler Toledo as a option.

Control type:
1: button control

2. PLC control:use Siemens PLC S200 (S300 as a option), Siemens HMI(3-LEVEL password and Recipe management as option).
