stainless steel Vacuum Emulsifying Machine 380V with electrical heating

Product description

Vacuum emulsifying mixer as a semi solid equipment are suitable for the pharmaceutical & cosmetic industries for making cream, ointment, lotion, soft gel, toothpaste, hair color.
Vacuum emulsifying mixer is a coaxial and triple type mixer, suitable to stable homogenizing and emulsifying. Relying on mixing of reversed impeller, under the condition of homogenizing turbine and vacuum status, you can get the high-quality effect of emulsifying and mixing.

Vacuum emulsifying mixer has very good performance in the aspect of insuring high quality of the finished material.

Working Principle

The working principle of the machine is according to the production process will be a variety of raw material in turn into the paste machine, all kinds of raw materials by strong mixing, kneading, grinding make full dispersion and mixing evenly, the vacuum degassing into a paste.

· Capacity:5L-5000L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS

Vacuum emulsifying equipment including:
· Vacuum emulsifying main machine
· Pre-mixing tank for water and oil material
· Vacuum system
· Hydraulic system
· Control system
· Platform made from SS304

Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.
