100L stainless steel 316L Vacuum Planetary Mixer for cosmetic cream

Product description

Vacuum Planetary Mixer is including main mixing, oil tank, water tank, and platform. The machine is including heating and cooling function.

There is a heat preservation layer outside the jacket. The homogenizer and the blade stirring can work together or separately. The material will be sliming, emulsifying, mixing, dispersing, etc. in a short time. The parts Contact the product adopt high-quality stainless steel (medical usage adopt SS 316L. the interior surface is mirror polished 400 MESH, vacuum mixing device is hygiene class. It's produced according to cGMP standard. It is the most ideal production equipment for cream and lotion.)

1 The heating method mainly includes electric or steam heating for customer's choice.

2 Advanced PLC touch screen control is optional.

3 The emulsifying pot lid can adopt hydraulic lifting system, easy to clean and the cleaning effect is more obvious, the emulsifying pot can adopt tilting discharge or use rotor pump for material out .

Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.093Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.

NOTE: Due to make toothpaste, the motor power have different type, so pls contact us, we will choose a suitable machine for you. we have engineer work for toothpaste factory more than 10 year also have machinery design experience.
