High Efficency Vacuum Homogenizer Mixer For Food And Beverage Industry​

Vacuum Homogenizer Mixer Features and Advantages

1. The self-suction type AES dissolver can shorten dissolving time, so as to save energy consumption and shorten production period.

2. Material can be heating or cooled according to technolgical requirements . The heating methods such as steam or electric heating can be selected according to customer requirements.

3. Various forms of blending vanes are suitable for production of different types of production of products.

4. Made of imported SUS304 orSUS316L stainless steel .The tank body and pipe are subjected to mirror polishing .

5. Bottom installation type dispersing head and SPX Pipeline type emulsifying head are optional to speed up dissolution and emulsification of materials .

Vacuum Homogenizer Mixer Parameter

· Capacity:100L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS


Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.
